凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (68.180.10) - TWINE PIVOT ELECTRIC Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
479 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
0C
|
[1] |
ORDER COMPONENTS
|
NH
Twine Pivot
|
| 2. |
84308004
|
[1] |
HUB
|
NH
|
| 3. |
84318531
|
[1] |
ARM
|
NH
|
| 4. |
86516818
|
[1] |
CONNECTING LINK
|
GI
|
| 5. |
84377502
|
[1] |
ELECTRIC MOTOR
|
NH
|
| 6. |
84258225
|
[1] |
SPROCKET,RC35, 11T
|
NH
11T RC35
|
| 7. |
86977396
|
[1] |
POTENTIOMETER,3000 Ohm, 16 VDC
|
PA
|
| 8. |
86000439
|
[1] |
SNAP RING,0.288" ID x 0.66" OD x 0.037" Thk, External
|
NH
|
| 9. |
84259286
|
[1] |
CHAIN,35, 83 Links x 3/8" = 31-1/8" L
|
NH
83 Pitches, Includes: Ref. 4 & 15
|
| 10. |
86505868
|
[1] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 11. |
9672521
|
[2] |
LOCK WASHER,Ext Tooth, #10
|
WIN
|
| 12. |
86613601
|
[1] |
WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk
|
NH
Urethane
|
| 13. |
412255
|
[2] |
BOLT,Hex, M4 x 20mm, Cl 8.8
|
NH
|
| 14. |
9804256
|
[3] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 15. |
117226
|
[1] |
OFFSET LINK
|
GI
Superseded by part number: 241-3713
|
