凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (68.180.09) - TWINE PIVOT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
539 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84235131
|
[1] |
MOUNT
|
NH
Twine Arms
|
| 2. |
84235133
|
[1] |
ARM
|
NH
Twine, Includes: (2) Ref. 12
|
| 3. |
84256613
|
[1] |
ARM
|
NH
Twine
|
| 4. |
84283485
|
[1] |
ANGLE
|
NH
|
| 5. |
87609767
|
[2] |
LEAF SPRING
|
NH
|
| 6. |
84247408
|
[1] |
SPROCKET,RC 35, 72T
|
PLO
|
| 7. |
84235136
|
[1] |
MOUNT
|
NH
Potentiometer
|
| 8. |
84235139
|
[1] |
SHIELD
|
NH
Trash
|
| 9. |
84370723
|
[1] |
ARM
|
NH
|
| 10. |
86637656
|
[4] |
RIVET,Pop, 1/8" x .337"
|
FAR
|
| 11. |
300595
|
[1] |
COTTER PIN,M4 x 40
|
WIN
Superseded by part number: 10733901
|
| 12. |
420434
|
[2] |
BUSHING,30mm ID x 34mm OD x 20mm L
|
NH
|
| 13. |
84255641
|
[2] |
SPACER
|
NH
|
| 14. |
47558620
|
[4] |
SPACER
|
NH
|
| 15. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 16. |
606943
|
[1] |
LUBE NIPPLE,1/8"-27 NPT x 1.76" lg
|
PA
|
| 17. |
140109
|
[2] |
WASHER,31mm ID x 40mm OD x 2mm Thk
|
NH
|
| 18. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 19. |
9804255
|
[2] |
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 20. |
844-10090
|
[1] |
BOLT,Hvy Hex, M10 x 90mm, Cl 8.8
|
CAS
|
| 21. |
9804263
|
[1] |
BOLT,M10 x 49.2mm, Cl 8.8
|
NH
|
| 22. |
9804278
|
[2] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
