凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (68.180.12[01]) - BALE SIZE INDICATOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
532 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84255654
|
[1] |
PANEL
|
NH
Bale Size
|
| 2. |
9619090
|
[1] |
CAP COVER
|
NH
|
| 3. |
9804277
|
[8] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 4. |
84235151
|
[1] |
MOUNTING CLIP
|
NH
|
| 5. |
9612212
|
[1] |
INDICATOR
|
NH
|
| 6. |
689986
|
[1] |
ANGLE
|
NH
|
| 7. |
43128
|
[2] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 8. |
84236908
|
[1] |
CABLE
|
NH
|
| 9. |
510932
|
[1] |
PULLEY,50.01mm OD
|
NH
|
| 10. |
696365
|
[1] |
SPACER
|
NH
|
| 11. |
86507486
|
[5] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 12. |
217208
|
[1] |
SPRING
|
PA
|
| 13. |
86619060
|
[3] |
CARRIAGE BOLT,M8 x 1.25 x 16mm, Cl 8.8
|
NH
|
| 14. |
281020
|
[1] |
SELF-TAP SCREW,Pan HD, #8 - 18 x 3/4"
|
NH
|
