凯斯零件查询(RB455A) - UTILITY CASE IH ROUND BALER (1/10-12/14) (88.068.04) - DIA KIT, REAR NET STORAGE Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
535 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84354115
|
[1] |
DIA KIT, HARVESTER
|
NH
|
| 2. |
84379818
|
[1] |
LID
|
NH
Net Storage
|
| 3. |
86000448
|
[2] |
LATCH
|
NH
|
| 4. |
9617447
|
[1] |
ROLL PIN
|
NH
|
| 5. |
308761
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 6. |
9804256
|
[4] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 7. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 8. |
9804277
|
[4] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 9. |
86619800
|
[4] |
FLANGE NUT,M6 x 1, Cl 8
|
RAC
|
| 10. |
87577454
|
[1] |
BOX
|
NH
Net Storage
|
