| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
|
[1] |
Turbocharger
|
|
| 2. |
VOE14346139
|
[1] |
Exhaust pipe
|
|
| 3. |
VOE424629
|
[1] |
Gasket
|
|
| 4. |
VOE924064
|
[6] |
Stud
|
|
| 5. |
VOE943705
|
[3] |
Tab washer
|
|
| 6. |
VOE946330
|
[6] |
Hexagon nut
|
|
| 7. |
VOE14239787
|
[1] |
Stay
|
|
| 8. |
VOE13970947
|
[1] |
Hexagon screw
|
(14014607)
|
| 9. |
VOE971071
|
[1] |
Hexagon nut
|
(14015041)
|
| 10. |
VOE14239790
|
[1] |
Attaching lug
|
|
| 11. |
VOE13970949
|
[1] |
Hexagon screw
|
(14014609)
|
| 12. |
VOE14015134
|
[1] |
Washer
|
|
| 13. |
VOE971071
|
[1] |
Hexagon nut
|
(14015041)
|
| 14. |
VOE13955295
|
[2] |
Screw
|
(14014597)
|
| 15. |
VOE14012733
|
[1] |
Silencer
|
|
| 16. |
VOE14047704
|
[1] |
Clamp
|
|
| 17. |
VOE14346149
|
[1] |
Stay
|
|
| 18. |
VOE13970951
|
[1] |
Hexagon screw
|
(14014611)
|
| 19. |
VOE971071
|
[1] |
Hexagon nut
|
(14015041)
|
| 20. |
VOE14252182
|
[1] |
Spacer
|
|
| 21. |
VOE965197
|
[1] |
Flange screw
|
|
| 22. |
VOE14015146
|
[1] |
Washer
|
|
| 23. |
VOE14256595
|
[1] |
Bracket
|
|
| 24. |
VOE13965185
|
[4] |
Screw
|
|
| 25. |
VOE14015146
|
[1] |
Washer
|
|
| 26. |
VOE14232794
|
[1] |
Clamp
|
|
| 27. |
VOE13970959
|
[2] |
Hexagon screw
|
(14014615)
|
| 28. |
VOE971071
|
[4] |
Hexagon nut
|
(14015041)
|
| 29. |
VOE14256848
|
[1] |
Tube
|
|
| |
VOE14248824
|
[1] |
Pipe elbow
|
|
| 30. |
VOE14213925
|
[1] |
Clamp
|
|
| |
VOE14024293
|
[ERF] |
Locking fluid
|
|
