斗山零件查询MAIN PIPING(3) - ARM, BUCKET DX235LC-5 Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
928 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-09194
|
[-] |
|
|
| 101. |
2181-1950D9
|
[1] |
PLUG
|
|
| 102. |
S8000291
|
[1] |
O-RING
|
|
| 22. |
2181-9078
|
[5] |
FLANGE;SPLIT
|
|
| 25. |
2181-9083
|
[1] |
FLANGE;SPLIT
|
|
| 39. |
S2212266
|
[4] |
BOLT
|
|
| 40. |
S2212466
|
[8] |
BOLT
|
|
| 47. |
DS2856003
|
[5] |
O-RING
|
|
| 51. |
DS20401178
|
[1] |
|
|
| 52. |
DS20401177
|
[1] |
|
|
| 53. |
DS20401132
|
[1] |
|
|
| 53. |
DS2040564
|
[1] |
HOSE
|
|
| 54. |
2181-1950D9
|
[1] |
PLUG
|
|
| 55. |
S8000291
|
[1] |
O-RING
|
|
| 56. |
DS2856002
|
[2] |
O-RING
|
|
| 57. |
DS2856003
|
[1] |
O-RING
|
|
| 6. |
2181-2620
|
[2] |
BLOCK;SPACER
|
|
