凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (01.82) - POWER TAKE OFF, 540 RPM, SLIP CLUTCH, EUROPE & R.O.W., SILAGE BALERS, P.I.N. Y8N038894 & AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
904 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87711423
|
[1] |
PTO
|
PLO
540 RPM with Slip Clutch
|
| 2. |
87517823
|
[2] |
BEARING ASSY
|
BEL
Cross & Bearing
|
| 3. |
87517822
|
[1] |
YOKE
|
BEL
1-3/8", Standard
|
| 3. |
87675559
|
[1] |
YOKE
|
NH
1-3/4", Optional
|
| 4. |
87517824
|
[1] |
YOKE
|
BEL
Front
|
| 5. |
87517825
|
[1] |
YOKE
|
BEL
Central
|
| 6. |
87517826
|
[1] |
ROLL PIN,10.5mm OD x 95mm L
|
BEL
|
| 7. |
87484409
|
[1] |
TUBE,1055 mm L
|
PA
Superseded by part number: 87517827
|
| 8. |
87517828
|
[1] |
INNER SHIELD
|
BEL
Superseded by part number: 87484368
|
| 9. |
84036368
|
[1] |
ROLL PIN
|
ZED
|
| 10. |
87517829
|
[1] |
YOKE
|
BEL
|
| 11. |
87484410
|
[1] |
PTO CLUTCH
|
PA
|
| 12. |
87018244
|
[1] |
CROSS
|
RAC
Journal Superseded by part number: 84355352
|
| 13. |
87012758
|
[2] |
LUBE NIPPLE
|
PA
LUBRICATOR Superseded by part number: 84036369
|
| 14. |
87517831
|
[1] |
BEARING COVER,89.4 mm ID x 132 mm OD x 12 mm
|
BEL
Bearing
|
| 15. |
87517832
|
[1] |
BEARING COVER,128.4 mm ID x 187 mm OD x 11 mm
|
BEL
Bearing Superseded by part number: 87587199
|
| 16. |
87517838
|
[1] |
COLLAR ASSY.
|
BEL
Single Chain Restraint
|
| 17. |
86979196
|
[1] |
BEARING,86mm ID x 132mm OD x 12mm H
|
PA
|
| 20. |
86979198
|
[1] |
CHAIN,229mm L
|
PA
Safety
|
| 21. |
87484373
|
[1] |
SPACER
|
PA
|
| 22. |
849472
|
[1] |
DANGER DECAL
|
NH
English
|
| 22. |
849483
|
[1] |
DANGER DECAL
|
NH
French
|
| 23. |
86520950
|
[1] |
DECAL
|
PA
DANGER, English Superseded by part number: 47475712
|
| 24. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Cover
|
| 25. |
87012736
|
[8] |
BOLT AND NUT
|
PA
& Nut
|
| 26. |
86979201
|
[1] |
YOKE
|
PA
Flange
|
| 27. |
86984909
|
[1] |
BUSHING
|
EML
Superseded by part number: 84026575
|
| 28. |
84011442
|
[2] |
DISC
|
ZED
Superseded by part number: 86517364
|
| 29. |
86625864
|
[1] |
HUB
|
NH
|
| 30. |
86625865
|
[1] |
KIT
|
NH
Tapered
|
| 31. |
86625863
|
[1] |
THRUST PLATE
|
NH
|
| 32. |
87484374
|
[1] |
BELLEVILLE SPRING
|
PA
|
| 33. |
87518984
|
[1] |
FRONT PTO ASSY
|
BEL
|
| 34. |
87484411
|
[1] |
PTO SHAFT
|
PA
|
| 35. |
87518987
|
[1] |
REPAIR KIT
|
BEL
Safety Shield
|
| 37. |
87587209
|
[1] |
KIT
|
ZED
Ball Collar
|
| 40. |
321204
|
[4] |
LUBE NIPPLE,M6 x 1.0 x 16mm OAL
|
ZED
|
| 42. |
933205R91
|
[1] |
LUBE NIPPLE,90 Degree, M8 x 1.25
|
IH
|
