凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (01.91[2]) - POWER TAKE OFF, SLIP CLUTCH, 540 RPM, NORTH AMERICA, P.I.N. Y8N038894 & AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
537 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47898152
|
[1] |
PTO
|
NH
Slip Clutch, 1200nM, Incl 2 - 35
|
| 2. |
87518490
|
[1] |
YOKE
|
BEL
Incl 35
|
| 3. |
87517787
|
[1] |
U-JOINT SPIDER
|
BEL
|
| 4. |
87520072
|
[1] |
YOKE
|
BEL
Front
|
| 5. |
87517785
|
[1] |
BODY
|
BEL
|
| 6. |
87520073
|
[1] |
ROLL PIN
|
BEL
Superseded by part number: 87586147
|
| 7. |
47841229
|
[1] |
PTO SHAFT,1170mm L
|
NH
Drive Tube, Outer
|
| 8. |
47898159
|
[1] |
PTO SHAFT,1170mm L
|
NH
Drive Tube, Inner
|
| 9. |
86625846
|
[1] |
PIN
|
NH
Superseded by part number: 87586150
|
| 10. |
274240
|
[1] |
YOKE
|
GI
Rear
|
| 11. |
87518571
|
[1] |
SLIP CLUTCH
|
BEL
Incl 23, 27 - 34
|
| 12. |
87520078
|
[1] |
SPIDER ,U-JOINT
|
BEL
Superseded by part number: 84355315
|
| 13. |
87012758
|
[1] |
LUBE NIPPLE
|
PA
Superseded by part number: 84036369
|
| 14. |
84383919
|
[1] |
SHIELD
|
PA
Bearing, Outer
|
| 15. |
87517775
|
[1] |
SHIELD
|
BEL
Bearing, Front
|
| 16. |
PL
|
[6] |
PROCURE LOCALLY
|
BAS
Self-Tapping Screw
|
| 17. |
84383920
|
[1] |
SHIELD
|
PA
|
| 19. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Safety Shield, Incl in 26
|
| 20. |
849472
|
[1] |
DANGER DECAL
|
NH
Shield Missing
|
| 21. |
849471
|
[1] |
DANGER DECAL
|
NH
Rotating Driveline
|
| 23. |
87012136
|
[1] |
REPAIR KIT
|
PA
Bolt and Nut
|
| 24. |
47841309
|
[1] |
PTO SHAFT
|
NH
Front, Incl 2 - 7
|
| 25. |
47898155
|
[1] |
PTO SHAFT
|
NH
Rear, Incl 8 - 11
|
| 26. |
47841325
|
[1] |
SHIELD
|
NH
Complete, Incl 14 - 22
|
| 27. |
84011442
|
[1] |
DISC
|
ZED
Superseded by part number: 86517364
|
| 28. |
86625864
|
[1] |
HUB
|
NH
|
| 29. |
86625863
|
[1] |
THRUST PLATE
|
NH
|
| 30. |
86625869
|
[1] |
SPACER
|
NH
|
| 31. |
87518582
|
[1] |
SPRING
|
BEL
|
| 32. |
86984909
|
[1] |
BUSHING
|
EML
Superseded by part number: 84026575
|
| 33. |
86625860
|
[1] |
CLUTCH PLATE
|
NH
Superseded by part number: 86625849, 86625849, 87012732
|
| 34. |
86625865
|
[1] |
KIT
|
NH
Taper Pin
|
| 35. |
86625855
|
[1] |
KIT
|
NH
Spring Superseded by part number: 87461438
|
