纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (0.530[01]) - MUFFLER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
164 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76089031 | [1] | SUPPORT | LEC |
| 2. | 76095065 | [1] | MUFFLER | LEC |
| 3. | 76089029 | [1] | EXHAUST SYSTEM PIPE,85.00 mm ID x 382.00 mm | LEC |
| 4. | 76089030 | [1] | SUPPORT | LEC |
| 7. | 11701721 | [1] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 9. | 12647001 | [4] | WASHER,M8 x 25 x 2.5 | FOR8.15X21 Superseded by part number: |
| 10. | 11106231 | [6] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 11. | 76079394 | [2] | SUPPORT | LEC |
| 12. | 76095064 | [1] | EXTENSION | LEC |
| 14. | 76076957 | [1] | CLAMP | LEC |
| 15. | 76079395 | [1] | BRACKET | LEC |
| 17. | 16043831 | [4] | SCREW,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd | BHB Superseded by part number: |
| 18. | 14496631 | [5] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
