| 1. |
87535325
|
[1] |
WIRE HARNESS
|
NH
|
| 2. |
87545062
|
[2] |
TAIL LAMP
|
NH
|
| 4. |
646223
|
[8] |
STRAP,8.0" L
|
PA
Superseded by part number: 95874S
|
| 6. |
86561136
|
[1] |
MODULE
|
NH
|
| 8. |
87673596
|
[2] |
STEEL PLATE
|
NH
|
| 10. |
86010402
|
[4] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 11. |
93867
|
[2] |
TUBE,10.49 mm ID x 15.09 mm OD x 15240 mm L, Bulk
|
PA
Superseded by part number: 258985
|
| 12. |
263117
|
[11] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 13. |
9804258
|
[6] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 15. |
88146
|
[2] |
BOLT,Hex, 1/4" - 20 x 1", Gr 5
|
PA
Superseded by part number: 86505867
|
| 17. |
20356
|
[2] |
NUT,1/4"-20, GB
|
PA
Superseded by part number: 280129
|
| 18. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 19. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 20. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 21. |
80701
|
[2] |
WASHER,0.31" ID x 0.73" OD x 0.07" Thk
|
NH
|
| 22. |
86610200
|
[6] |
THREADED INSERT,M8 x 1.25
|
NH
|
| 23. |
9804276
|
[1] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 24. |
9804256
|
[1] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 25. |
570821
|
[1] |
SELF-TAP SCREW,Hex Flng, 5/16" - 18 x 5/8"
|
NH
|
| 26. |
86512495
|
[4] |
FLANGE NUT,Hex, M5, Cl 8
|
PA
|
| 27. |
322356
|
[4] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
|
