| 1. |
86631464
|
[2] |
BRACKET
|
NH
|
| 2. |
BER746294
|
[2] |
HYDRAULIC SYSTEM
|
BER
Red
|
| 3. |
86631462
|
[1] |
BRACKET
|
NH
|
| 4. |
84037090
|
[1] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
Red
|
| 5. |
258985
|
[1] |
GROMMET
|
PA
Plastic Tube Superseded by part number: 86632155
|
| 6. |
9818147
|
[12] |
CLAMP
|
ZED
|
| 7. |
515-23127
|
[10] |
CLAMP,1/2", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86010402
|
| 8. |
86618111
|
[1] |
WIRE HARNESS
|
NH
Lighting
|
| 9. |
86610201
|
[4] |
INSERT,M8
|
NH
Threaded, M8
|
| 10. |
84037093
|
[1] |
TAIL LAMP,12V, 21W, Amber/Red
|
ZED
Clear
|
| 11. |
86631486
|
[1] |
BRACKET
|
NH
|
| 12. |
84600729
|
[2] |
SUPPORT
|
PLO
|
| 13. |
86618112
|
[1] |
WIRE HARNESS
|
NH
LH Extension
|
| 14. |
86615932
|
[2] |
BRACKET
|
NH
Superseded by part number: 87370803
|
| 15. |
799266
|
[2] |
LAMP REFLECTOR
|
NH
White
|
| 16. |
470016
|
[2] |
BULB
|
NH
12V, 10W Superseded by part number: E35556
|
| 17. |
336483
|
[2] |
POSITION LAMP
|
NH
LIGHT, TAIL
|
| 18. |
435895
|
[4] |
REFLECTOR,80mm OD, Orange
|
NH
Yellow, Pickup LH & RH
|
| 19. |
529070
|
[2] |
CABLE TIE,368.3mm L
|
NH
CABLE STRAP
|
| 20. |
86614960
|
[1] |
WIRE HARNESS
|
NH
Main
|
| 21. |
418870
|
[2] |
BULB,12V, 10W
|
NH
12V, 10W Superseded by part number: 14149590
|
| 22. |
398877
|
[4] |
BULB,12V, 21W
|
NH
Superseded by part number: 14148190
|
| 24. |
86511042
|
[4] |
SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8
|
ZED
Superseded by part number: 13272214
|
| 25. |
9706703
|
[6] |
CARRIAGE BOLT,Sht Sq Nk, M6 x 1 x 20mm, Cl 8.8, Full Thd
|
NH
|
| 26. |
844-8020
|
[8] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 27. |
811-8020
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 28. |
577927
|
[2] |
CLAMP,12.7mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
3/4", 13/32" Bolt
|
| 29. |
825-2406
|
[7] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 30. |
825-2408
|
[9] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 31. |
825-1404
|
[4] |
NUT,M4, Cl 8
|
CAS
Superseded by part number: 57121
|
| 32. |
86566990
|
[2] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
CABLE STRAP
|
| 33. |
86511825
|
[4] |
SCREW,Phillips Drive, Pan HD, M4 x 30mm, Cl 4.8
|
NH
|
| 34. |
844-6020
|
[2] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 35. |
322357
|
[7] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 36. |
322358
|
[12] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 37. |
322355
|
[4] |
BELLEVILLE WASHER,M4 Bolt Size x 10mm OD x 0.9mm Thk
|
NH
|
| 39. |
322356
|
[6] |
BELLEVILLE WASHER,M5 Bolt Size x 12mm OD x 1.85mm Thk
|
ZED
|
| 41. |
86618113
|
[1] |
WIRE HARNESS
|
NH
|
| 42. |
86511830
|
[2] |
SCREW,Phillips Drive, Pan HD, M6 x 20mm, Cl 4.8
|
ZED
|
| 43. |
9507807
|
[6] |
CLAMP,8.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 44. |
677808
|
[1] |
SELF-TAP SCREW,Hex Flng, 1/4" - 20 x 5/8"
|
NH
HWH, 1/4"-20 x 5/8"
|
| 45. |
570821
|
[2] |
SELF-TAP SCREW,Hex Flng, 5/16" - 18 x 5/8"
|
NH
Flg, USR, 5/16"-18 x 5/8"
|
