| 1. |
86511226
|
[1] |
SHIELD
|
NH
|
| 2. |
86637389
|
[2] |
SPRING
|
NH
|
| 3. |
86637391
|
[2] |
ARM
|
NH
|
| 4. |
177822
|
[2] |
SPACER,8.33mm ID x 12.7mm OD x 4.32mm Thk
|
NH
21/64" ID x .500" OD x .170" Lg.
|
| 5. |
217465
|
[2] |
SPRING
|
NH
Extension
|
| 6. |
86619565
|
[2] |
SUPPORT
|
NH
|
| 7. |
86509329
|
[2] |
MOUNTING PLATE
|
NH
Superseded by part number: 87362420
|
| 8. |
86000439
|
[2] |
SNAP RING,0.288" ID x 0.66" OD x 0.037" Thk, External
|
NH
|
| 9. |
515-2279
|
[4] |
CLAMP,5/16", Insul, 5/16" Bolt
|
CAS
Superseded by part number: 853764
|
| 10. |
86506979
|
[1] |
SHIELD
|
NH
|
| 11. |
86610200
|
[2] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
| 12. |
718782
|
[4] |
SPACER
|
NH
|
| 13. |
86977396
|
[2] |
POTENTIOMETER,3000 Ohm, 16 VDC
|
PA
Bale Shape
|
| 14. |
86613601
|
[2] |
WASHER,14.88mm ID x 28.69mm OD x 7.35mm Thk
|
NH
Urethane
|
| 16. |
614-4020
|
[4] |
BOLT,Hex, M4 x 0.7 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 412255
|
| 17. |
614-8020
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm
|
CAS
Superseded by part number: 120104
|
| 18. |
844-8020
|
[6] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 19. |
120040
|
[4] |
CARRIAGE BOLT,Short Nk, M8 x 80mm, Cl 8.8
|
NH
|
| 22. |
493-41020
|
[4] |
LOCK WASHER,Ext Tooth, #10
|
CAS
Superseded by part number: 9672521
|
| 23. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 24. |
495-21038
|
[4] |
WASHER,5/16"
|
CAS
Superseded by part number: 80664, 72187263
|
| 26. |
825-2408
|
[8] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
