凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (08.46[2]) - SHIELDS, REAR, NORTH AMERICA, P.I.N. Y7N016414 & AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
450 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86729594
|
[1] |
SHIELD
|
NH
|
| 2. |
86632429
|
[1] |
SUPPORT
|
NH
|
| 4. |
86631186
|
[1] |
SUPPORT
|
NH
RH
|
| 5. |
87673593
|
[1] |
SHIELD
|
NH
Rear, RH
|
| 6. |
86643221
|
[1] |
DOOR ASSY.
|
NH
|
| 7. |
632732
|
[2] |
LATCH
|
NH
|
| 8. |
86631288
|
[1] |
SUPPORT
|
NH
|
| 9. |
87673590
|
[1] |
SHIELD
|
NH
Rear, LH
|
| 11. |
86624292
|
[1] |
SUPPORT
|
NH
|
| 12. |
86625685
|
[1] |
SUPPORT
|
NH
LH
|
| 13. |
86632470
|
[1] |
SUPPORT
|
NH
|
| 14. |
86729592
|
[1] |
SHIELD
|
NH
LH
|
| 20. |
9804256
|
[2] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 21. |
9804258
|
[42] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 22. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 23. |
322358
|
[42] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 24. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 25. |
9804277
|
[16] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 27. |
86610200
|
[26] |
THREADED INSERT,M8 x 1.25
|
NH
|
