凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (08.47) - SHIELDS, REAR, EUROPE & R.O.W. Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
541 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
86729594
|
[1] |
SHIELD
|
NH
RH
|
| 2. |
86632429
|
[1] |
SUPPORT
|
NH
|
| 3. |
87624160
|
[1] |
SHIELD
|
NH
|
| 4. |
86631186
|
[1] |
SUPPORT
|
NH
RH
|
| 5. |
87027815
|
[1] |
SHIELD
|
PA
RH
|
| 6. |
86643221
|
[1] |
DOOR ASSY.
|
NH
|
| 7. |
632732
|
[1] |
LATCH
|
NH
|
| 8. |
86631288
|
[1] |
SUPPORT
|
NH
RH
|
| 9. |
87027814
|
[1] |
SHIELD
|
PA
LH
|
| 10. |
86980311
|
[1] |
SHIELD
|
NH
|
| 11. |
86624292
|
[1] |
SUPPORT
|
NH
|
| 12. |
86625685
|
[1] |
SUPPORT
|
NH
LH
|
| 13. |
86632470
|
[1] |
SUPPORT
|
NH
|
| 14. |
86729592
|
[1] |
SHIELD
|
NH
LH
|
| 15. |
86630876
|
[2] |
WHEEL CHOCK
|
PLO
Superseded by part number: 86553668
|
| 16. |
86630877
|
[2] |
SUPPORT
|
PLO
Chock Superseded by part number: 86553669
|
| 17. |
9706732
|
[2] |
CLAMP,19mm ID, 8.7mm Bolt Hole, P Type
|
NH
Superseded by part number: 86637976
|
| 19. |
844-8025
|
[10] |
BOLT,Hvy Hex, M8 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 9671714
|
| 20. |
844-6020
|
[2] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 21. |
844-8020
|
[54] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 22. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 23. |
322358
|
[62] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 24. |
825-2406
|
[2] |
FLANGE NUT,M6 x 1, Cl 8.8
|
CAS
Superseded by part number: 9804276
|
| 25. |
825-2408
|
[22] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 26. |
86505868
|
[5] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
| 27. |
86610200
|
[34] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
