纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (6.711[04]) - ELECTRICAL SYSTEM - ELECTRIC WIRING New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
979 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 10450290 | [1] | CLAMP,12mm, Coat, 9mm Bolt Hole, P Type | LEC74X9 Superseded by part number: 86625036 |
| 2. | 10450490 | [1] | CLAMP,16mm, Coat, 9mm Bolt Hole, P Type | LEC9mm hole dia. Superseded by part number: |
| 3. | 10902431 | [2] | SCREW,Hex, M6 x 20mm, Cl 10.9 | LEC Superseded by part number: 86505530 |
| 4. | 15896221 | [2] | NUT,Hex, M6, 5.20mm High, Cl 10 | ZED Superseded by part number: 86500688 |
| 5. | 14496431 | [2] | WASHER,6.4mm ID x 12.5mm OD x 1.6mm Thk | LEC Superseded by part number: 86588450 |
| 6. | 76052577 | [2] | ELEC CONNECTOR | LEC- SOLENOID VALVE |
| 7. | 76068106 | [2] | ELECTRIC CABLE | LEC- SOLENOID VALVE |
| 8. | 16043031 | [1] | BOLT,Hex, M8 x 12mm, Cl 10.9, Full Thd | LEC Superseded by part number: 43231 |
| 9. | 14496531 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 10. | 76075401 | [1] | WIRE HARNESS | LEC- SOLENOID VALVE |
