纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (2.344[02A]) - TRACK ROLLERS - VERSION (02-03) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
362 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79103265 | [2] | PLATE | LEC |
| 2. | 76029444 | [1] | ROLLER SHAFT | LEC |
| 3. | 79021308 | [2] | SUPPORT | LEC |
| 4. | 79110878 | [1] | TRACK ROLLER | LEC |
| 5. | 79103235 | [2] | CASE | LEC- ASSY |
| 6. | 79103239 | [2] | GASKET | LEC Superseded by part number: 79007451 |
| 7. | 79019318 | [1] | PLUG | LEC |
| 8. | 14457080 | [1] | O-RING,0.103" Thk x 0.487" ID, -112, Cl 5, 75 Duro | LEC Superseded by part number: 86637641 |
| 9. | 14233430 | [12] | SCREW,M10 x 1.25 x 25mm | LEC10X1,25X25 Superseded by part number: 16323434 |
| 10. | 14465680 | [2] | O-RING,0.139" Thk x 3.484" ID, -238, Cl 5, 75 Duro | TTF Superseded by part number: 14465681 |
| 12. | 76003935 | [1] | DOWEL | LEC |
| 13. | 79103236 | [1] | BUSHING | LEC |
| 14. | 76089203 | [10] | TRACK ROLLER | LEC- ASSY Superseded by part number: 76089202 |
| 15. | 15981331 | [40] | BOLT,Hex, M16 x 1.5 x 75mm, Cl 10.9 | MKT Superseded by part number: 15981334 |
| 16. | 14496931 | [40] | WASHER,17mm ID x 30mm OD x 3mm Thk | IMO Superseded by part number: 86625266 |
| 11. | 14464580 | [2] | O-RING,0.139" Thk x 2.109" ID, -227, Cl 5, 75 Duro | TTF Superseded by part number: 510121 |
