纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (2.346[01]) - TRACK IDLER - WHEEL New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
886 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76030720 | [2] | IDLER WHEEL | LEC Superseded by part number: 79022524 |
| 2. | 76029503 | [2] | SHAFT | LEC |
| 3. | 79103235 | [4] | CASE | LEC- ASSY |
| 4. | 79103239 | [2] | GASKET | LEC Superseded by part number: 79007451 |
| 5. | 79019318 | [2] | PLUG | LEC |
| 6. | 14233431 | [24] | BOLT,Hex, M10 x 1.25 x 25mm, Cl 10.9, Full Thd | TTF10X1,25X25 Superseded by part number: 14233434 |
| 7. | 15984431 | [4] | BOLT,Hex, M18 x 1.5 x 55mm, Cl 10.9, Full Thd | LEC Superseded by part number: 15984424 |
| 8. | 14497031 | [4] | WASHER,M18 x 34 | LEC |
| 9. | 14465680 | [4] | O-RING,0.139" Thk x 3.484" ID, -238, Cl 5, 75 Duro | TTF Superseded by part number: 14465681 |
| 11. | 14457080 | [2] | O-RING,0.103" Thk x 0.487" ID, -112, Cl 5, 75 Duro | LEC Superseded by part number: 86637641 |
| 12. | 76003935 | [1] | DOWEL | LEC |
| 13. | 79103236 | [1] | BUSHING | LEC |
| 10. | 14464580 | [4] | O-RING,0.139" Thk x 2.109" ID, -227, Cl 5, 75 Duro | TTF Superseded by part number: 510121 |
