纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (2.346[04]) - TRACK IDLER - YOKE - VERSION (01-04) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
482 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76045697 | [2] | ROD | LEC |
| 3. | 14496931 | [16] | WASHER,17mm ID x 30mm OD x 3mm Thk | IMO Superseded by part number: 86625266 |
| 4. | 14497131 | [4] | WASHER,21mm ID x 37mm OD x 3mm Thk | LEC Superseded by part number: 140021 |
| 5. | 76089211 | [2] | PLATE | LEC- FRONT |
| 6. | 76041402 | [4] | SCREW,Hex, M20 x 2.5 x 220mm | LEC20X2,5X22 |
| 7. | 15981031 | [16] | BOLT,Hex, M16 x 1.5 x 55mm, Cl 10.9 | TTF |
| 9. | 76089210 | [2] | SUPPORT | LEC |
| 10. | 76089207 | [2] | SUPPORT | LEC Superseded by part number: 76053501 |
| 12. | 76089212 | [2] | PLATE | LEC |
