纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.440[03A]) - PAT CYLINDERS 7 ROLLERS - OPTIONAL CODE 784181041 - 784181051 - VERSION (02-03) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
276 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76089120 | [1] | FLEXIBLE HOSE | LEC |
| 2. | 76089121 | [1] | FLEXIBLE HOSE | LEC |
| 3. | 12626231 | [3] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 4. | 76041055 | [1] | COLLAR CLAMP | LEC |
| 6. | 76076902 | [2] | TIE-ROD | LEC |
| 7. | 11106431 | [5] | SCREW,Hex, M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 9515003 |
