| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 186-3735 | [4] | PIN-CONNECTOR(16-GA TO 18-GA) | |
| 2. | 134-6748 | [2] | SCREW-LENS | |
| 3. | 102-8804 | [1] | KIT-RECEPTACLE(4-PIN) | |
| (INCLUDES RECEPTACLE AS & WEDGE) | ||||
| 4. | 8T-0288M | [2] | BOLT(M5X0.8X12-MM) | |
| 5. | 8F-1434 | [2] | LOCKWASHER | |
| 6. | 9X-4493 | [2] | LAMP(24-VOLT, 21-WATT)(TURN SIGNAL) | |
| 7. | 130-3565 | [1] | LAMP(24-VOLT) | |
| 8. | 134-6750 | [1] | LENS(STOP, TAIL, TURN) | |
| M | METRIC PART | |||
