神钢零件查询(6D22-TC) - MITSUBISHI DIESEL ENGINE - K912, K912LC, & K916 (1/83-12/06) (02-019) - INTER COOLER GENERAL Kobelco
广数供应链运营团队, 18 02月, 2025，浏览：
146 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-10. | VAME058792 | [1] | AIRCOND. COMPRESSOR | KOBAIR CHARGE COOLER ASSY, M0 ONLY Superseded by part number: 136060A1 |
| . . | VAME157176 | [1] | M2 ONLY | |
| 1. | VAME058793 | [1] | MANIFOLD INTER COOLER, M0 ONLY | MANIFOLD INTER COOLER, M0 ONLY |
| . . | VAME157177 | [1] | M2 ONLY | |
| 2. | VAME058697 | [1] | COVER, INTER COOLER | |
| 3. | VAME058695 | [1] | INTERCOOLER | KOBCORE ASSY Superseded by part number: 136063A1 |
| 4. | VAME058698 | [2] | PLATE ASSY | |
| 5. | VAME058701 | [2] | GASKET | KOB Superseded by part number: 136064A1 |
| 6. | VAME058700 | [2] | GASKET | KOB |
| 7. | VAMF244857 | [29] | SCREW | KOBBOLT, W/WSR 8X35 Superseded by part number: 134848A1 |
| 8. | VAMH000223 | [3] | SCREW | KOBBOLT, W/WSR 8X115 Superseded by part number: 134847A1 |
| 9. | VAME058702 | [2] | HYD CONNECTOR | KOB Superseded by part number: 136073A1 |
| 10. | VAMF520022 | [4] | O-RING | KOBO-RING 30 Superseded by part number: 136076A1 |
| 12. | VAMH023451 | [2] | STAY | |
| 13. | VAMH023452 | [1] | STAY | |
| 14. | VAMF303363 | [6] | SPECIAL WASHER | KOBBOLT, W/WSR 10X25 Superseded by part number: 132364A1 |
| 16. | VAMH002165 | [5] | STUD | HITSTUD 10X125 Superseded by part number: 134845A1 |
| 17. | VAMF407016 | [6] | STUD | KOBSTUD 10X60 Superseded by part number: 134842A1 |
| IS. | VAMF407023 | [1] | STUD | KOBSTUD 10X100 Superseded by part number: 134843A1 |
| 19. | VAMF434105 | [12] | NUT | KOBNUT, FLANGE 10 |
| 20. | VAME059362 | [1] | PIPE | KOBINLET |
| 21. | VAMH000706 | [1] | SCREW | KOBBOLT, FLANGE 10X16 Superseded by part number: 132289A1 |
| 22. | VAME059366 | [1] | PIPE, WATER RETURN | PIPE, WATER RETURN |
| 23. | VAME059365 | [2] | GASKET | KOB Superseded by part number: 136065A1 |
| 24. | VAMH000707 | [4] | BOLT | KOBBOLT, FLANGE 10X30 |
| 25. | VAMD011382 | [2] | HOSE, SUPPLY | |
| 26. | VAMF661020 | [4] | HOSE CLAMP | KOBCLAMP, HOSE 40 Superseded by part number: 136077A1 |
| 27. | VAME059367 | [1] | PIPE | KOBPIPE, AIR ESCAPE Superseded by part number: 136070A1 |
| 28. | VAMH037279 | [1] | BOLT | KOBBOLT, EYE |
| . . | VAMF660063 | [2] | GASKET | KOBGASKET 10 Superseded by part number: VAF420210000 |
| 29. | VAMH038906 | [1] | HYD CONNECTOR | KOBCONNECTOR PT1/8-M14 Superseded by part number: 133327A1 |
| 30. | VAMH021233 | [4] | CLAMP | KOBCLAMP Superseded by part number: 133329A1 |
| 31. | VAMF140011 | [2] | SPECIAL BOLT | KOBBOLT, FLANGE 6X30 Superseded by part number: 133337A1 |
