纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.522[03]) - RIPPER (RP) - 'RECO' - 10F - OPTIONAL CODE 784177021 - VERSION (03) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
199 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 76031581 | [2] | HOSE | LEC |
| 3. | 70921115 | [8] | HALF-FLANGE | CMI Superseded by part number: 71404407 |
| 4. | 14463281 | [2] | O-RING,0.984" ID x 0.139" Width | TTF |
| 5. | 70930370 | [16] | WASHER,0.44" ID x 0.69" OD x 0.11" Thk | BHB |
| 6. | 70921565 | [16] | SCREW | LEC3/8-16X38 Superseded by part number: 20988 |
| 7. | 76031548 | [1] | MANIFOLD | LEC |
| 8. | 76031554 | [1] | SUPPORT | LEC |
| 9. | 15996931 | [2] | BOLT,Hex, M24 x 2 x 50mm, Cl 10.9, Full Thd | LEC |
| 10. | 14497331 | [2] | WASHER,25mm ID x 44mm OD x 4mm Thk | LEC24X44 Superseded by part number: 86511328 |
| 11. | 70921175 | [2] | BOLT | LEC Superseded by part number: 9790143 |
| 12. | 70928178 | [2] | WASHER | BHB |
| 13. | 70921076 | [8] | SCREW,3/8"-16 x 1 1/4" | BHB Superseded by part number: 280165 |
| 14. | 76076843 | [1] | BRACKET | LEC Superseded by part number: 22276076843 |
