纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.522[04]) - RIPPER (RP) - 'RECO' - 10F - OPTIONAL CODE 784177021 - VERSION (03) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
907 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76031532 | [4] | BUSHING | LEC |
| 2. | 76031556 | [1] | BARREL | LEC |
| 3. | 8293355 | [1] | NUT | LEC |
| 4. | 76031557 | [1] | PISTON | LEC |
| 5. | 76031558 | [1] | SEAL | LEC Superseded by part number: 76031570 |
| 6. | 14463281 | [1] | O-RING,0.984" ID x 0.139" Width | TTF |
| 7. | 76031561 | [1] | GASKET | LEC Superseded by part number: 76031570 |
| 8. | 76031562 | [1] | SEAL | LEC Superseded by part number: 76031570 |
| 9. | 76031563 | [1] | SEAL | LEC Superseded by part number: 76031570 |
| 10. | 76031564 | [1] | SEAL | LEC Superseded by part number: 76031570 |
| 11. | 76031566 | [1] | MUDSCRAPER RING | LEC Superseded by part number: 76031570 |
| 12. | 76089434 | [1] | BASE PLATE | LEC Superseded by part number: 76031567 |
| 13. | 15984631 | [4] | BOLT,Hex, M18 x 1.5 x 70mm, Cl 10.9 | MOD18X1,5X70 Superseded by part number: 15984637 |
| 14. | 14497031 | [4] | WASHER,M18 x 34 | LEC |
| 15. | 76089435 | [1] | ROD | LEC Superseded by part number: 76031568 |
| 16. | 76031559 | [1] | O-RING | LEC Superseded by part number: 76031570 |
| 17. | 13407211 | [1] | LUBE NIPPLE,M10 x 1 | TTF Superseded by part number: 84351730 |
| 18. | 70921565 | [5] | SCREW | LEC Superseded by part number: 20988 |
| 19. | 70930370 | [5] | WASHER,0.44" ID x 0.69" OD x 0.11" Thk | BHB |
| 20. | 76089437 | [1] | HYD. TUBE | LEC Superseded by part number: 76031569 |
