纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.651[10]) - ROPS CANOPY - COMPONENTS - OPTIONAL CODE 784111201 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
678 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76067706 | [1] | REAR VIEW MIRROR | LEC |
| 2. | 76067260 | [1] | SUPPORT | LEC |
| 3. | 16043424 | [2] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 8.8, Full Thd | TTF |
| 4. | 14496534 | [2] | WASHER,M8 | BURx 17 Superseded by part number: 86624184 |
| 5. | 4227139 | [2] | CAP,M8 | LEC Superseded by part number: 9964997 |
| 6. | 76067386 | [1] | HANDLE | LEC |
| 7. | 10979221 | [2] | BOLT,Hex, M10 x 1.5 x 16mm, Cl 8.8 | MKT Superseded by part number: 10979224 |
| 8. | 14496601 | [2] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | BAS Superseded by part number: |
| 30. | 76301022 | [1] | SEAL | LEC- LEFT |
| 31. | 76301023 | [1] | SEAL | LEC- RIGHT |
| 33. | 76301295 | [2] | STRAP | LEC |
| 34. | 76067740 | [22] | THREADED INSERT | BURM5 Superseded by part number: 71490908 |
| 35. | 13274411 | [18] | SCREW,Pozidriv Pan Hd, M5 x 20mm | TTF Superseded by part number: 86511827 |
| 36. | 14496304 | [18] | WASHER | BUR5X10 |
| 37. | 10571479 | [16] | LOCK WASHER,M5 | LEC Superseded by part number: |
