纽荷兰零件查询(D150) - CRAWLER DOZER (1/05-) (9.703[01]) - SUPPLEMENTARY LIGHTS - OPTIONAL CODE 784333001 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
540 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76040180 | [2] | HEADLAMP | LEC- ASSY |
| 2. | 76041296 | [1] | SEAL | LEC |
| 3. | 76041297 | [1] | LENS | LEC |
| 4. | 79069460 | [1] | BULB | LEC Superseded by part number: 14151690 |
| 5. | 76041298 | [1] | | |
| 6. | 76041299 | [2] | SPACER | LEC |
| 7. | 76041300 | [2] | RUBBER WASHER | LEC |
| 8. | 76041264 | [4] | SCREW | LEC |
| 9. | 76041263 | [1] | LOCK NUT | LEC |
| 10. | 76041261 | [1] | SCREW | LEC |
| 11. | 76041262 | [1] | BRACKET | LEC |
| 12. | 76041301 | [1] | WASHER | LEC |
| 13. | 76041302 | [1] | NUT | LEC |
| 14. | 4809591 | [1] | ELECTRIC CABLE | LEC |
| 15. | 79096843 | [1] | RUBBER RING | LEC |
| 16. | 76041254 | [1] | LENS | LEC |
| 17. | 71480911 | [2] | DUST CAP | LEC |
