凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (18.85[2]) - DIA KIT, DENSITY CYLINDER SYSTEM BYPASS, HYDRAULIC VALVE & PIPES Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
969 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84493051
|
[1] |
HYDRAULIC MANIFOLD
|
NH
|
| 2. |
76350
|
[2] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
Includes: Ref. 14
|
| 3. |
129274
|
[3] |
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BHB
|
| 4. |
84488921
|
[1] |
HYD TUBE
|
NH
Includes: (2) Ref. 15 & (2) Ref. 16
|
| 5. |
84488923
|
[1] |
HYD TUBE
|
NH
Includes: (2) Ref. 15 & (2) Ref. 16
|
| 6. |
76344
|
[1] |
90 ELBOW,9/16" - 18 JIC x 9/16" - 18 ORB
|
NH
|
| 7. |
574342
|
[1] |
CAP,9/16" - 18 JIC
|
LEC
|
| 8. |
84483532
|
[1] |
SUPPORT
|
NH
|
| 9. |
82012728
|
[1] |
COLLAR,50mm - 65mm, Worm Gear
|
NH
Superseded by part number: 82036462
|
| 10. |
86511840
|
[2] |
BOLT,Hex Flng, M6 x 1 x 40mm, Cl 8.8
|
NH
|
| 11. |
322357
|
[2] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 12. |
9804276
|
[2] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 13. |
84484161
|
[1] |
INSTRUCTION
|
NH
|
| 14. |
9617873
|
[1] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
| 15. |
136658
|
[4] |
TUBE NUT,0.72" Length
|
BEL
|
| 16. |
235670
|
[4] |
SLEEVE,37 Degree, 3/8" Tube
|
BEL
|
