凯斯零件查询(RB464) - CASE IH ROUND BALER (7/07-1/14) (18.85[3]) - DIA KIT, DENSITY CYLINDER SYSTEM BYPASS, HYDRAULIC CONTROL WIRE HARNESS Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
811 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84493501
|
[1] |
DIA KIT, HARVESTER
|
NH
Density Cylinder System Bypass, Hydraulic Control Wire Harness
|
| 2. |
84483760
|
[1] |
WIRE HARNESS
|
NH
Hydraulic Control
|
| 3. |
86624468
|
[1] |
SPACER,1.65" L x 5/16” Thk
|
NH
|
| 4. |
86594422
|
[1] |
SENSOR
|
NH
|
| 5. |
82017871
|
[1] |
RELAY,12V, 20A
|
BAS
Superseded by part number: 84411012
|
| 6. |
84483530
|
[1] |
SUPPORT
|
NH
|
| 7. |
9804277
|
[2] |
FLANGE NUT,Hex, M8 x 1.25, Cl 8
|
NH
Superseded by part number: 86505868
|
| 8. |
84483528
|
[1] |
SUPPORT
|
NH
|
| 9. |
86637978
|
[8] |
CLAMP,9.5mm, Coat, 8.7mm Bolt Hole, P Type
|
FAR
|
| 10. |
700514
|
[1] |
CLAMP,3.8mm, Coat, M8 Bolt
|
NH
|
| 11. |
86566989
|
[11] |
CABLE TIE,208mm L
|
ZED
CABLE STRAP
|
| 12. |
86900323
|
[2] |
NUT,#10 - 24
|
PA
|
| 13. |
86511842
|
[2] |
BOLT,M8 x 1.25 x 48.1mm OAL, Cl 8.8
|
NH
|
| 14. |
87310126
|
[2] |
SCREW,Phillips Drive, Pan HD, #10 - 24 x 3/4", SST
|
BUR
|
| 15. |
380426
|
[6] |
SCREW,Flng, M6 x 10mm
|
NH
|
| 16. |
322358
|
[2] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
