纽荷兰零件查询(D150C WT/LGP) - CRAWLER DOZER - TIER 4A (10/13-) (10.310.AA[02]) - AFTERCOOLER New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
164 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 84376173 | [1] | AFTERCOOLER | BUR |
| 2. | 87340284 | [2] | INTAKE AIR HOSE,76.20mm ID x 129mm L | FAR |
| 3. | L115549 | [8] | CLAMP,69.85mm - 92.08mm | CASHose |
| 4. | 84487552 | [1] | RIGID TUBE | BURAftercool |
| 5. | 84570287 | [1] | AIR INTAKE TUBE | BUR |
| 6. | 84570290 | [1] | INTAKE AIR HOSE,76.2mm ID x 221.7mm L | BURCac |
| 7. | J918685 | [1] | PIPE | CASTurbo Outlet Air Transfer |
| 8. | J069053 | [1] | CLAMP,66.54mm ID | LTurbo Outlet |
| 9. | J883284 | [1] | O-RING,0.07" Thk x 2.364" ID, -36 | CASSeal Superseded by part number: J883284AM |
| 10. | 217-402 | [1] | PLUG,Hex Hd, 1/8"-27 NPTF | CAS Superseded by part number: 88071 |
| 11. | 87572375 | [1] | HOSE,76.2mm ID x 89mm L | FAR |
