| 1. | 232-2448 | [1] | NUT,1/2"-20, GC | CAS |
| 2. | 86624188 | [1] | WASHER,0.53" ID x 1.06" OD x 0.13" Thk | GI |
| 3. | 87010656 | [4] | CLAMP,17.5mm, Coat, 10.3mm Bolt Hole, P Type | GI |
| 4. | 43139 | [2] | BOLT,M10 x 1.5 x 25mm, Cl 8.8 | NH Superseded by part number: 11106231, 11106231, BER43139 |
| 5. | 84062222 | [1] | BOLT,Hex, M10 x 45mm, Cl 8.8, Full Thd | NH Superseded by part number: 8900127036 |
| 6. | 337563 | [2] | SCREW,M12 x 1.75 x 47.68mm, Cl 10.9 | NH |
| 7. | 829-1410 | [1] | NUT,M10 x 1.5, Cl 10.9 | CASM12 x 1.75 Class 8 Superseded by part number: 86500689 |
| 8. | 87497916 | [2] | NUT | BRR Superseded by part number: 87497918 |
| 9. | 864-10020 | [6] | HEX SOC SCREW,M10 x 20mm, Cl 8.8 | CAS Superseded by part number: 86632600 |
| 10. | 43140 | [1] | BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8 | NHFan Drain |
| 11. | 84592530 | [1] | HYDRAULIC HOSE,9.53mm ID x 3060mm L, SAE 100R1 | BUR |
| 12. | 9840543 | [1] | 90 ELBOW,90°, 11/16"-16 x 9/16"-18 Adj, ORFS | WINIncl 26 - 25 |
| 13. | 86598103 | [2] | O-RING,2.9mm Thk x 23.6mm ID, Cl 6, 90 Duro | ZEDFan Motor |
| 14. | 84592532 | [2] | HYDRAULIC HOSE,19.05mm ID x 1670mm L, SAE 100R16 | BURFan Mount |
| 15. | 84474439 | [1] | HUB | BURPusher 700mm Diameter |
| 16. | 84385174 | [1] | FAN,9 Blades, 700mm OD | BURFan 19cc |
| 17. | 84398132 | [1] | HYDRAULIC PUMP,GEAR, 19 CC | BURIncl 28 - 31 |
| 17. | 84398132R | [1] | REMAN-HYD MOTOR | BURIncl 28 - 31 |
| 17. | 84398132C | [1] | CORE-MOTOR HYDRAULIC | BURReturn Number |
| 18. | 86579682 | [2] | HYD CONNECTOR,1-3/16" - 12 ORFS x M27 x 2 ORB | ZEDIncl 13, 24 |
| 19. | 87030549 | [1] | NUT,M10 x 1.5, Cl 10 | WICM12 x 13.65 x 24.9 x 3.2 Hts Boron |
| 20. | 87655043 | [2] | WASHER,M12, 13.65mm ID x 24.90mm OD x 3.20mm, HT Boron, ZNM | BURM10 x 10.65 x 23.0 x 2.2 Hts Boron |
| 21. | 87655046 | [12] | SPECIAL WASHER,10.65mm ID x 23mm OD x 2.2mm Thk | BURDouble 1.00"/25mm ID |
| 22. | D39696 | [2] | CLAMP,Double, 25.40mm Dia, Coated | CAS Superseded by part number: 47048664 |
| 23. | 167266 | [3] | O-RING,0.116" Thk x 0.924" ID, -912, Cl 6, 90 Duro | NH |
| 24. | 9991976 | [5] | O-RING,0.07" Thk x 0.739" ID, -18, Cl 6, 90 Duro | WIN |
| 25. | 9617873 | [1] | O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro | NH |
| 26. | 9993141 | [1] | O-RING,0.07" Thk x 0.364" ID, -12, Cl 6, 90 Duro | BAS |
| 27. | 84489989 | [1] | O-RING | FAR |
| 28. | 84489988 | [1] | SEAL | FAR |
| 29. | 84489987 | [1] | SHAFT SEAL | FAR |
| 30. | 84489986 | [1] | RING | FARRetaining |
| 31. | 84489985 | [1] | SEAL | FARM10 x 1.5 |
| 32. | 87417721 | [1] | THREADED INSERT,M10 x 1.5-6H x 29 L | BURM10 x 1.5 |
| 33. | 9993143 | [1] | HYD CONNECTOR,11/16" - 16 ORFS x 9/16" - 18 ORB | IMO |
| 34. | 9840535 | [2] | HYD CONNECTOR,1-3/16" - 12 ORFS x 1-1/16" - 12 ORB | NH Superseded by part number: 87393627 |
