神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (01-012) - TIMING GEAR Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
451 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CT-KS03 | [1] | TIMING GEAR(M0) | |
| . . | 6D22Z ALL | [1] | TIMING GEAR(M0) | |
| 1. | VAME062311 | [1] | GEAR CRANKSHAFT Z = 63 | GEAR CRANKSHAFT Z = 63 |
| 2-5. | VAME062842 | [1] | GEAR | KOBIDLER ASSY |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, A IDLER Z=33 |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, B IDLER Z=66 |
| 4. | VAME062905 | [1] | BUSHING | KOBIDLER Superseded by part number: 132529A1 |
| 5. | VAMS476135 | [1] | KEY | KOBWOODRUFF 5X19 Superseded by part number: 132499A1 |
| 6. | VA3092311600 | [2] | IDLER SHAFT | IDLER SHAFT |
| 8. | VAMH012037 | [2] | PIN | KOBSPG 5.4X10 Superseded by part number: 132322A1 |
| 10-11. | VAME052369 | [1] | GEAR ASSY IDLER IDLER ASSY | GEAR ASSY IDLER IDLER ASSY |
| 10. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, C IDLER Z=68 |
| 11. | VAME062905 | [1] | BUSHING | KOBIDLER Superseded by part number: 132529A1 |
| 12. | VA3092312300 | [2] | BOLT IDLER SHAFT | BOLT IDLER SHAFT |
| 14. | VAME062326 | [2] | THRUST PLATE | KOBTHRUST |
| 15. | VAME062573 | [2] | COLLAR CLAMP | KOB Superseded by part number: 132541A1 |
| 17. | VAMF430009 | [2] | NUT | KOB16 |
| 19. | VAMF520583 | [2] | O-RING | KOB35 |
| 21. | VA3112304100 | [2] | O-RING | KOB15 Superseded by part number: 132546A1 |
| 22. | VAME051184 | [1] | GEAR CAMSHAFT Z=63 | GEAR CAMSHAFT Z=63 |
| 23. | VAMH004074 | [1] | NUT | KOB |
| 24. | VAME062323 | [1] | WASHER | KOBLOCK |
| 25-25A. | VAME052538 | [1] | INJECTION PUMP GEAR | |
| 25. | VAME052537 | [1] | GEAR | KOBI/PZ=63 |
| 25A. | VAMF472402 | [1] | PIN | KOBDOWEL |
| 26. | VAME052602 | [1] | PLATE | KOBSENSOR |
| 27. | VAMH004075 | [1] | NUT | KOB |
| 2S. | VA3117502109 | [1] | WASHER | KOBLOCK |
| 29. | VA3090702900 | [1] | PLUG | KOBOIL SPRAY Superseded by part number: 132538A1 |
