凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (35.540.AI[03]) - VAR - 727159 - BALE TENSION HYDRAULICS, SINGLE CYLINDER, IN CAB CONTROL, YFN188619 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
261 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84549526
|
[1] |
HYDRAULIC CYLINDER
|
NH
Bale Tension, Serial Range: -797322005
|
| 1. |
47860094
|
[1] |
HYDRAULIC CYLINDER
|
PLO
Bale Tension, Start Serial: 797324001
|
| 2. |
47765085
|
[1] |
HYDRAULIC VALVE
|
PLO
Proportional Relief, Incl 12-14, 19
|
| 3. |
574342
|
[1] |
CAP,9/16" - 18 JIC
|
LEC
|
| 4. |
86505972
|
[2] |
BOLT,5/16" - 18 x 2 - 1/4", Gr 5
|
BAS
|
| 5. |
47765917
|
[1] |
TUBE
|
PLO
Incl 16-17, Serial Range: -797322005
|
| 5. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Hyd. Tube, Incl 16-17, Start Serial: 797324001
|
| 6. |
76350
|
[1] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
Incl 18
|
| 7. |
86013710
|
[1] |
FITTING
|
WIN
Quick Connect
|
| 8. |
86502604
|
[1] |
DUST CAP
|
WIN
Black
|
| 9. |
9625178
|
[2] |
PLUG,9/16" - 18 ORB
|
BEL
|
| 10. |
163335
|
[1] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
Incl 18
|
| 11. |
80681
|
[1] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 12. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Hydraulic Valve, Poppit Relief
|
| 13. |
84227091
|
[1] |
COIL
|
GI
Superseded by part number: 920019798
|
| 14. |
47775189
|
[1] |
HYDRAULIC VALVE
|
PLO
Incl 15
|
| 15. |
84320139
|
[1] |
O-RING,2.2mm Thk x 11.3mm ID
|
ZED
|
| 16. |
235670
|
[1] |
SLEEVE,37 Degree, 3/8" Tube
|
BEL
|
| 17. |
136658
|
[1] |
TUBE NUT,0.72" Length
|
BEL
|
| 18. |
9617873
|
[2] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
| 19. |
86523197
|
[1] |
SENSOR
|
ZED
|
