凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (35.540.AI[04]) - VAR - 726815 - BALE TENSION HYDRAULICS, DUAL CYLINDER ASSEMBLY, YFN188618 AND PRIOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
766 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47471577
|
[1] |
HYDRAULIC MANIFOLD
|
PLO
Bale Tension
|
| 2. |
47624452
|
[1] |
HYDRAULIC CYLINDER
|
NH
LH
|
| 3. |
84563528
|
[1] |
HYDRAULIC HOSE,6.3mm ID x 2794mm L, SAE 100R17
|
NH
2974 mm
|
| 4. |
574342
|
[1] |
CAP,9/16" - 18 JIC
|
LEC
|
| 5. |
84563527
|
[1] |
HYDRAULIC HOSE
|
NH
Cylinder Base End
|
| 6. |
84563526
|
[1] |
HYDRAULIC HOSE
|
NH
Cylinder Rod End
|
| 7. |
76350
|
[2] |
HYD CONNECTOR,9/16" - 18 ORB x 9/16" - 18 JIC
|
NH
Incl 18
|
| 8. |
84549525
|
[1] |
HYDRAULIC CYLINDER
|
NH
RH
|
| 9. |
84552131
|
[1] |
HYD TUBE
|
NH
RH Bale Density,661 mm, Incl 19, 20
|
| 10. |
86505972
|
[2] |
BOLT,5/16" - 18 x 2 - 1/4", Gr 5
|
BAS
|
| 11. |
86513020
|
[2] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
|
| 12. |
163335
|
[1] |
TEE,9/16" - 18 ORB x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BEL
Incl 18
|
| 13. |
80681
|
[2] |
LOCK NUT,5/16"
|
NH
Superseded by part number: 83990583
|
| 14. |
86513049
|
[1] |
PLUG,9/16" - 18 JIC
|
WIN
|
| 15. |
129274
|
[1] |
TEE,9/16" - 18 JIC x 9/16" - 18 JIC x 9/16" - 18 JIC
|
BHB
|
| 16. |
101792A1
|
[1] |
COUPLING
|
CAS
Diagnostic
|
| 17. |
86502604
|
[1] |
DUST CAP
|
WIN
Black
|
| 18. |
9617873
|
[2] |
O-RING,0.078" Thk x 0.468" ID, -906, Cl 6, 90 Duro
|
NH
|
| 19. |
136658
|
[2] |
TUBE NUT,0.72" Length
|
BEL
|
| 20. |
235670
|
[2] |
SLEEVE,37 Degree, 3/8" Tube
|
BEL
|
