凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (35.550.AB[01]) - TAILGATE, HYDRAULIC CYLINDER, YFN188619 AND AFTER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
368 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87019623
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 31.75mm Rod, 685.8mm Stroke
|
RAC
Tailgate Lift, Incl 2 - 13
|
| 2. |
NSS
|
[1] |
NOT SOLD SEPARAT
|
CON
Cylinder Barrel, Incl in 1
|
| 3. |
87025449
|
[1] |
HEAD
|
PA
Cylinder
|
| 4. |
9843627
|
[1] |
WEAR RING,Split, 31.75mm ID x 34.8mm OD x 12.7mm Thk
|
NH
Wear, 1.250 ID x .50 Thk
|
| 5. |
235782
|
[1] |
O-RING,0.139" Thk x 1.734" ID, -224, Cl 6, 90 Duro
|
WIN
|
| 6. |
270103
|
[1] |
BACK-UP RING,45.01mm ID x 51mm OD x 1.27mm Thk
|
NH
Backup, 1.772 ID x .043 Thk
|
| 7. |
86513307
|
[1] |
SEAL,31.75mm ID x 37.85mm OD x 6.35mm Thk
|
NH
Double-Lip, 1.50 OD x 1.25 ID x .250 Tk.
|
| 8. |
529340
|
[1] |
SEAL,31.75mm ID x 43.05mm OD x 4.76mm Thk
|
NH
Rod Wiper
|
| 9. |
87025447
|
[1] |
PISTON ROD
|
PA
|
| 10. |
280724
|
[1] |
LOCK NUT,3/4" - 16
|
NH
|
| 11. |
87025448
|
[1] |
PISTON
|
PA
|
| 12. |
771705
|
[1] |
RING
|
NH
Wear, 2.004 ID x .50 Thk
|
| 13. |
86553483
|
[1] |
SEAL
|
NH
Piston, 3 Piece
|
| 14. |
87025443
|
[1] |
SEAL KIT
|
PA
Kit, Incl 4 - 8, 12 - 13
|
