卡特零件查询（725） 148-9983: LINES GP-SERVICE BRAKE
广数供应链运营团队, 14 02月, 2025，浏览：
329 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 6U-0456 | [2] | STRAP | |
| 2. | 7U-6574 | [2] | SEAL | |
| 3. | 164-5586 | [1] | TEE AS | |
| | 7X-0871 | [1] | TEE | |
| | 6V-8398 | [1] | SEAL-O-RING | |
| 4. | 173-6219Y | [1] | VALVE GP-CHK & PRESS REDUCING(SERVICE BRAKE) | |
| 5. | 179-9401I | [1] | HOSE AS | |
| 6. | 179-9402I | [1] | HOSE AS | |
| 7. | 179-9403I | [2] | HOSE AS | |
| 8. | 179-9405I | [1] | HOSE AS | |
| 9. | 179-9406I | [1] | HOSE AS | |
| 10. | 179-9407I | [1] | HOSE AS | |
| 11. | 179-9414 | [1] | TUBE AS | |
| 12. | 179-9415 | [1] | TUBE AS | |
| 13. | 179-9416 | [1] | TUBE AS | |
| 14. | 179-9417 | [1] | TUBE AS | |
| 15. | 179-9418 | [1] | TUBE AS | |
| 16. | 179-9421 | [1] | TUBE AS | |
| 17. | 179-9423 | [1] | BRACKET | |
| 18. | 179-9424 | [1] | BRACKET | |
| 19. | 188-9629 | [1] | BRACKET | |
| 20. | 199-3667 | [1] | TUBE AS | |
| 21. | 199-3668I | [1] | HOSE AS | |
| 22. | 201-4032I | [1] | HOSE AS | |
| 23. | 118-9573M | [4] | BOLT-12 POINT HEAD(M10X1.5X35-MM) | |
| 24. | 148-8336 | [1] | CONNECTOR AS | |
| | 6V-8636 | [1] | CONNECTOR | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| 25. | 148-8340 | [3] | CONNECTOR AS | |
| | | | (EACH INCLUDES) |
| | 6V-8639 | [1] | CONNECTOR | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| | 6V-8398 | [1] | SEAL-O-RING | |
| 26. | 148-8364 | [1] | ELBOW AS | |
| | 6V-8625 | [1] | ELBOW | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| | 6V-8398 | [1] | SEAL-O-RING | |
| 27. | 148-8370 | [2] | ELBOW AS | |
| | | | (EACH INCLUDES) |
| | 6V-9851 | [1] | ELBOW | |
| | 6V-8398 | [1] | SEAL-O-RING | |
| 28. | 148-8411 | [1] | PLUG AS | |
| | 9S-4185 | [1] | PLUG(3/4-16-THD) | |
| | 3K-0360 | [1] | SEAL-O-RING | |
| 29. | 148-8415 | [1] | REDUCER AS | |
| | 6V-8936 | [1] | REDUCER | |
| | 6V-8397 | [1] | SEAL-O-RING | |
| 30. | 148-8427 | [4] | TEE AS | |
| | | | (EACH INCLUDES) |
| | 8T-6895 | [1] | TEE-UNION | |
| | 6V-8398 | [3] | SEAL-O-RING | |
| 31. | 148-8457 | [3] | UNION AS(STRAIGHT) | |
| | | | (EACH INCLUDES) |
| | 6V-8995 | [1] | UNION(STRAIGHT) | |
| | 6V-8398 | [2] | SEAL-O-RING | |
| 32. | 150-4043 | [1] | CONNECTOR AS | |
| | 6V-9873 | [1] | CONNECTOR | |
| | 3J-1907 | [1] | SEAL-O-RING | |
| | 6V-8398 | [1] | SEAL-O-RING | |
| 33. | 2U-2749 | [1] | CLIP | |
| 34. | 3U-2428 | [3] | CLAMP-PIPE | |
| 35. | 4J-5267 | [1] | SEAL-O-RING | |
| 36. | 5P-7464 | [3] | CLIP(SLOT) | |
| 37. | 5P-7465 | [3] | CLIP(TAB) | |
| 38. | 6V-7359 | [3] | GROMMET(25-MM ID, 37-MM OD) | |
| 39. | 6V-8398 | [2] | SEAL-O-RING | |
| 40. | 6V-9169 | [7] | NUT(13/16-16-THD) | |
| 41. | 7X-7729 | [1] | WASHER(11X25X3-MM THK) | |
| 42. | 8C-3205 | [2] | FLANGE-HALF | |
| 43. | 8R-9400 | [1] | CLAMP | |
| 44. | 8T-1885 | [4] | CLIP(SLOT) | |
| 45. | 8T-1886 | [4] | CLIP(TAB) | |
| 46. | 8T-1887 | [3] | CLIP(SLOT) | |
| 47. | 8T-1888 | [3] | CLIP(TAB) | |
| 48. | 8T-4121 | [22] | WASHER-HARD(11X21X2.5-MM THK) | |
| 49. | 8T-4123 | [7] | WASHER(22X35X3.5-MM THK) | |
| 50. | 8T-4133M | [8] | NUT(M10X1.5-THD) | |
| 51. | 8T-4137M | [2] | BOLT(M10X1.5X20-MM) | |
| 52. | 8T-4177M | [2] | BOLT(M8X1.25X90-MM) | |
| 53. | 8T-4183M | [2] | BOLT(M12X1.75X40-MM) | |
| 54. | 8T-4195M | [8] | BOLT(M10X1.5X30-MM) | |
| 55. | 8T-4223 | [4] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 56. | 8T-4224 | [2] | WASHER-HARD(8.8X16X2-MM THK) | |
| 57. | 8T-4244M | [1] | NUT(M12X1.75-THD) | |
| 58. | 8T-4956M | [1] | BOLT(M12X1.75X35-MM) | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
