神钢零件查询(6D22C) - MITSUBISHI DIESEL ENGINE - K909A, K910, K912 & K935 (1/76-12/06) (05-003) - EMERGENCY PARTS Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
199 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 6D221CZ-KS0A | [1] | EMERGENCY PARTS(M4) | |
| 1. | VA3089804100 | [1] | SOLENOID | KOBSTOP 24V ND |
| 2. | VAMF240049 | [4] | BOLT, W/WSR 8X12 | |
| 3. | VA303320590 | [1] | ROD L=590 | |
| . . | VAMC010080 | [2] | BALL JOINT | KOB Superseded by part number: 240384A1 |
| 5. | VAMF430724 | [2] | NUT 6 | |
| 8. | VAMF445003 | [2] | NUT, SELF LOCK 6 | |
| 15. | VAME059949 | [1] | BRACKET, SOLENOID | |
| 16. | VAMF300841 | [1] | SCREW | KOBW/WSR 10X20 Superseded by part number: 132461A1 |
| 17. | VAMS306008 | [2] | BOLT, W/WSR 10X95 | |
| 18. | VAMC820467 | [2] | SPACER L=3.2 | |
