凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (60.220.CC[04]) - VAR - 726917 - 1.8M TINE WINDGUARD, USED WITHOUT TOP ASSIST ROLL Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
858 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47361881
|
[2] |
ARM
|
NH
|
| 2. |
84495729
|
[1] |
WINDGUARD
|
NH
|
| 3. |
84238738
|
[2] |
SPACER,10.34mm ID x 15.88mm OD x 12mm L
|
NH
|
| 4. |
80702
|
[6] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 5. |
9804262
|
[2] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 6. |
9804278
|
[6] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 7. |
87027237
|
[2] |
CHAIN,18 Links x 37.2mm = 670mm L
|
PA
Superseded by part number: 87055684
|
| 8. |
88902
|
[2] |
NUT,3/8"-16
|
NH
|
| 9. |
86575418
|
[2] |
BOLT,Hex, 3/8" - 16 x 2 1/4", Gr 8
|
NH
|
| 10. |
86508947
|
[2] |
LINCH PIN,18.8mm OD
|
NH
|
| 11. |
80756
|
[2] |
COTTER PIN,1/8" x 3/4"
|
NH
|
| 12. |
197559
|
[2] |
CHAIN,9" L
|
NH
|
| 13. |
47362955
|
[1] |
WINDGUARD
|
NH
|
| 14. |
47467993
|
[2] |
RETAINER
|
NH
|
| 15. |
86633356
|
[4] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
