| 1. |
84308045
|
[1] |
MOUNT
|
NH
|
| 2. |
47478963
|
[1] |
CRANKED HANDLE
|
NH
|
| 3. |
47478955
|
[1] |
LINK
|
NH
|
| 4. |
374892
|
[1] |
CARRIAGE BOLT,M10 x 1.5 x 40mm, Cl 8.8
|
NH
|
| 5. |
47541232
|
[1] |
TUBE
|
PLO
Superseded by part number: 47701399
|
| 6. |
47541270
|
[1] |
ARM
|
PLO
|
| 7. |
84312850
|
[1] |
MOUNT
|
PLO
Incl 33
|
| 8. |
33781
|
[1] |
KNOB
|
NH
|
| 9. |
86632592
|
[2] |
WASHER,1.06" ID x 2" OD x 0.13" Thk
|
FOR
|
| 10. |
47438768
|
[1] |
ARM
|
NH
|
| 11. |
90999
|
[1] |
SPACER,25.65mm ID x 50.8mm OD x 15.88mm L
|
NH
|
| 12. |
47605440
|
[2] |
BELLEVILLE WASHER,M22 Bolt Size x 50mm OD x 3mm Thk
|
NH
|
| 13. |
9628503
|
[2] |
NUT,3/8"-16, G5
|
NH
|
| 14. |
88444
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 3/4", Gr 5
|
NH
|
| 15. |
280315
|
[1] |
GROOVED PIN,4.76mm OD x 25.4mm L
|
NH
|
| 16. |
122257
|
[4] |
WASHER,61.9mm ID x 77.79mm OD x 1.2mm Thk
|
NH
|
| 17. |
86636631
|
[1] |
HUB
|
NH
|
| 18. |
249100
|
[3] |
WASHER,0.78" ID x 1.25" OD x 0.06" Thk
|
NH
|
| 19. |
80738
|
[2] |
COTTER PIN,3/16" x 1 1/4"
|
GI
Superseded by part number: 87398
|
| 20. |
87569
|
[1] |
LUBE NIPPLE,45 Degree, 1/4" NPT x 4/5" L, Drive
|
PA
|
| 21. |
87020910
|
[2] |
SPACER,10.4mm ID x 19mm OD x 8.9mm Thk
|
PA
|
| 22. |
213404
|
[2] |
SPACER,10.3mm ID x 38.1mm OD x 5.2mm OAL
|
NH
|
| 23. |
9804263
|
[1] |
BOLT,M10 x 49.2mm, Cl 8.8
|
NH
|
| 24. |
235126
|
[2] |
WASHER,10.3mm ID x 38mm OD x 1.7mm Thk
|
NH
|
| 25. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 26. |
9804278
|
[6] |
FLANGE NUT,M10 x 1.5, Cl 8
|
NH
|
| 27. |
9804262
|
[4] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 28. |
9804261
|
[4] |
BOLT,Hex, M10 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 29. |
120074
|
[2] |
BOLT,Hex, M10 x 90, 8.8
|
NH
|
| 30. |
100037
|
[2] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 31. |
47532616
|
[1] |
SPACER
|
PLO
|
| 32. |
47437161
|
[1] |
PIN
|
NH
|
| 33. |
86620198
|
[1] |
BUSHING
|
NH
|
