| 1. |
47377066
|
[1] |
PLATE
|
NH
|
| 2. |
84602660
|
[1] |
IDLER
|
NH
15T
|
| 3. |
84414870
|
[1] |
CHAIN
|
PLO
RC60, 92 Pitches, Inc 34
|
| 4. |
84488186
|
[1] |
SHIELD
|
NH
|
| 5. |
84485546
|
[1] |
SHIELD
|
NH
|
| 6. |
47456909
|
[1] |
DOOR
|
NH
|
| 7. |
84290564
|
[1] |
COVER
|
NH
|
| 8. |
47325
|
[1] |
CLIP
|
NH
|
| 9. |
9804276
|
[7] |
FLANGE NUT,Hex, M6 x 1, Cl 8
|
NH
|
| 10. |
9804255
|
[4] |
BOLT,Hex, M6 x 1 x 16mm, Full Thd, Cl 8.8
|
NH
|
| 11. |
9804256
|
[6] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 12. |
86610198
|
[9] |
INSERT,M6 x 1
|
NH
|
| 13. |
322357
|
[3] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 14. |
9804257
|
[3] |
FLANGE BOLT,Hex, M6 x 1.0 x 25mm, Cl 8.8, Full Thd
|
NH
|
| 15. |
385683
|
[1] |
BOLT,M4 x 0.7 x 12.92mm, Cl 8.8
|
NH
Superseded by part number: 5113531
|
| 16. |
9824840
|
[1] |
WASHER,4.3mm ID x 9mm OD x 0.8mm Thk
|
NH
Superseded by part number: 89824840
|
| 17. |
100012
|
[1] |
NUT,M4 x 0.7, Cl 8
|
NH
Superseded by part number: 57121
|
| 18. |
130358
|
[2] |
WASHER,16.28mm ID x 38.35mm OD x 4.11mm Thk
|
NH
|
| 19. |
86509246
|
[1] |
NUT,M16, Cl 8
|
WIN
|
| 20. |
47487761
|
[1] |
CARRIAGE BOLT,Reg Sq Nk, M16 x 2 x 70mm, Cl 8.8
|
NH
|
| 21. |
84487233
|
[1] |
COVER
|
NH
|
| 22. |
140048
|
[1] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
XtraSweep
|
| 23. |
9705390
|
[1] |
LATCH
|
NH
Superseded by part number: 81866169
|
| 24. |
84549560
|
[1] |
SHIELD
|
NH
|
| 25. |
9840986
|
[1] |
CLIP
|
NH
|
| 26. |
87304
|
[2] |
NUT,#10-24
|
BEL
|
| 27. |
84821
|
[2] |
SCREW,Truss HD, #10 - 24 x 1/2"
|
NH
|
| 28. |
9804258
|
[2] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 29. |
165109
|
[1] |
DECAL
|
NH
Lube
|
| 30. |
86610199
|
[5] |
INSERT
|
PA
Superseded by part number: 84272827
|
| 31. |
86610201
|
[1] |
INSERT,M8
|
NH
|
| 32. |
86050272
|
[4] |
BOLT,M6 x 1 x 18.6mm OAL, Cl 8.8, Full Thd
|
NH
|
| 33. |
86512439
|
[3] |
CARRIAGE BOLT,M6 x 16mm, Cl 8.8
|
NH
|
| 34. |
84134452
|
[1] |
CONNECTING LINK,RC60, 3/4" Pitch
|
NH
|
