| 1. |
84349215
|
[1] |
SPROCKET,15T, RC80
|
PLO
15T, RC80, Fixed, RH
|
| 2. |
84533097
|
[1] |
SPROCKET,15T, RC80
|
PLO
15T, RC80, Pivot Roll
|
| 3. |
84350406
|
[1] |
SPROCKET
|
PLO
& Clutch Superseded by part number: 84370050
|
| 4. |
86705492
|
[1] |
CLUTCH
|
PA
Half Superseded by part number: 87660581
|
| 5. |
84401598
|
[1] |
SPROCKET,39.967mm ID x 118.4mm OD x 14.61mm Thk
|
GI
13T, RC80, Incl 48 Superseded by part number: 87011880
|
| 6. |
86511326
|
[2] |
WASHER,17mm ID x 30mm OD x 3mm Thk
|
NH
Superseded by part number: 80299
|
| 7. |
87647763
|
[1] |
ARM
|
NH
Incl 49
|
| 8. |
58821
|
[6] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
|
| 9. |
86624647
|
[2] |
WASHER,10.8mm ID x 57mm OD x 6.1mm Thk
|
NH
|
| 10. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 11. |
9804262
|
[2] |
BOLT,M10 x 39.2mm, Cl 8.8
|
NH
Superseded by part number: 9840672
|
| 12. |
87707866
|
[1] |
CHAIN
|
NH
37 Pitches, Incl 45, 46
|
| 12. |
87627269
|
[1] |
CHAIN (AG),80, 38 Links x 25.4mm = 965.2mm
|
NH
38 Pitches, Incl 47
|
| 13. |
47493781
|
[1] |
IDLER
|
NH
Block
|
| 14. |
29684
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
|
| 15. |
9804270
|
[1] |
BOLT,Hex, M12 x 60mm, Cl 8.8
|
NH
|
| 16. |
100038
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 17. |
170055
|
[1] |
KEY
|
ZED
Parallel Superseded by part number: 80170055
|
| 18. |
87495
|
[1] |
KEY,0.31" x 2.50" L
|
NH
Square
|
| 19. |
87644681
|
[8] |
SHIM,46mm ID x 60mm OD x 1.50mm Thk
|
POL
|
| 20. |
11487
|
[1] |
SNAP RING,#175, Ext
|
NH
|
| 21. |
196303
|
[1] |
SPRING,2.44" OD x 4.5" L
|
NH
Superseded by part number: 86640119
|
| 22. |
9829364
|
[1] |
CAP COVER
|
NH
|
| 23. |
84345656
|
[1] |
CHAIN,80, 62 Links x 25.4mm = 1574.8mm
|
PLO
Incl 46
|
| 24. |
86618213
|
[1] |
SPECIAL BOLT,M12 x 40mm, Drilled
|
NH
|
| 25. |
87054556
|
[1] |
TENSION SPRING
|
BEL
9.25" Long
|
| 26. |
86629541
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 27. |
9706685
|
[2] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 28. |
80702
|
[2] |
WASHER,0.44" ID x 1" OD x 0.08" Thk
|
NH
|
| 29. |
32318
|
[1] |
BUSHING,11.94mm ID x 17.27mm OD x 50.8mm L
|
NH
|
| 30. |
25121
|
[2] |
SNAP RING,#100, Ext
|
NH
|
| 31. |
26402
|
[6] |
WASHER,25.8mm ID x 38.1mm OD x 1.7mm Thk
|
NH
|
| 32. |
120090
|
[1] |
BOLT,Hex, M16 x 50mm, Cl 8.8
|
NH
|
| 33. |
9804280
|
[1] |
FLANGE NUT,Hex, M16, Cl 8
|
NH
Superseded by part number: 86512498
|
| 34. |
80710
|
[1] |
LUBE NIPPLE,1/8” – 27 Dryseal PTF
|
DUB
|
| 35. |
9628503
|
[2] |
NUT,3/8"-16, G5
|
NH
|
| 36. |
36835
|
[1] |
EYEBOLT,G2, 3/8"-16 x 6-1/2"
|
NH
|
| 37. |
47493774
|
[1] |
INDICATOR
|
NH
|
| 38. |
86635754
|
[1] |
SPRING,Compression, 1.029" OD x 2.73" L
|
NH
2.73" Long
|
| 39. |
47494243
|
[1] |
TENSIONER
|
NH
|
| 40. |
84376806
|
[1] |
SPACER,13mm ID x 31.75mm OD x 32.5mm L
|
PLO
|
| 41. |
47587896
|
[1] |
ARM
|
PLO
|
| 42. |
45455
|
[1] |
SPACER,13.5mm ID x 25.4mm OD x 9.5mm Thk
|
NH
|
| 43. |
80700
|
[4] |
WASHER,0.56" ID x 1.38" OD x 0.11" Thk
|
NH
|
| 44. |
300389
|
[1] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 45. |
86977428
|
[1] |
CONNECTING LINK
|
PA
Offset Superseded by part number: 241-1718
|
| 46. |
84356440
|
[1] |
LINK,25.4mm Pitch
|
NH
|
| 47. |
86643889
|
[1] |
CONNECTING LINK
|
NH
|
| 48. |
66553
|
[1] |
BALL BEARING,16.13mm ID x 40mm OD x 12.12mm W
|
NH
|
| 49. |
612945
|
[1] |
SPACER
|
PA
|
