沃尔沃零件查询D12D-A MH; D12D-B MH; D12D-C MH; D12D-E MH; D12D-G MH; D12C-A MP; D12D-A MP; D12D-B MP; D12D-C MP; D12D-D MP; D12D-E MP; D12D-F MP; D12D-G MIntake and Exhaust SystemCrankcase Ventilation, ClosedEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
1020 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
3888808
|
[1] |
Separator
|
(3885440)
|
| 2. |
973972
|
[1] |
Hose
|
L=150mm
|
| 3. |
853548
|
[6] |
Hose clamp
|
|
| 4. |
3884143
|
[1] |
Pipe
|
|
| 5. |
947827
|
[1] |
Clamp
|
|
| 6. |
|
|
|
|
| 7. |
3827462
|
[1] |
Hose connection
|
|
| 8. |
3165097
|
[1] |
Sealing ring
|
|
| 9. |
3165095
|
[1] |
Cup
|
|
| 10. |
3883318
|
[1] |
Pipe
|
|
| 11. |
965562
|
[2] |
Bracket
|
|
| 12. |
946440
|
[5] |
Flange screw
|
|
| 13. |
945408
|
[5] |
Flange nut
|
|
| 14. |
947827
|
[3] |
Clamp
|
|
| 15. |
965540
|
[1] |
Bracket
|
|
| 16. |
949747
|
[1] |
Clamp
|
|
| 17. |
191172
|
[1] |
Washer
|
|
| 18. |
945408
|
[1] |
Flange nut
|
|
| 19. |
946440
|
[1] |
Flange screw
|
|
| 20. |
3588722
|
[1] |
Oil hose
|
|
| 21. |
984716
|
[1] |
Nipple
|
|
| 22. |
11994
|
[1] |
Gasket
|
|
| 23. |
961670
|
[2] |
Hose clamp
|
|
| 24. |
3587290
|
[1] |
Hose
|
|
| 25. |
3587291
|
[1] |
Oil hose
|
|
| 26. |
20462497
|
[1] |
Connection pipe
|
|
| 27. |
20555696
|
[1] |
Sealing ring
|
(421629)
|
| 28. |
946440
|
[2] |
Flange screw
|
|
| 29. |
3587773
|
[1] |
Bracket
|
|
| 30. |
3587293
|
[1] |
Cover
|
|
| 31. |
948888
|
[1] |
O-ring
|
|
| 32. |
965197
|
[4] |
Flange screw
|
|
| 33. |
971096
|
[1] |
Flange nut
|
|
| 34. |
945444
|
[3] |
Flange screw
|
|
| 35. |
965553
|
[2] |
Bracket
|
|
