神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-002) - CRANKSHAFT BEARING Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
827 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-2. | VAME999711 | [1] | SET OF CONN ROD BRGS U/S | KOBMAIN BEARING SET ONE MODEL ,STD |
| 1-2. | VAME999712 | [1] | BEARING | KOBMAIN BEARING SET ONE MODEL, US 0.25 |
| 1-2. | VAME999713 | [1] | BEARING | KOBMAIN BEARING SET ONE MODEL, US 0.50 |
| 1-2. | VAME999714 | [1] | BEARING | KOBMAIN BEARING SET ONE MODEL, US 0.75 |
| 1-2. | VAME999715 | [1] | BEARING | KOBMAIN BEARING SET ONE MODEL, US 1.00 |
| 1. | NSS | [7] | NOT SOLD SEPARAT | CONBEARING,MAIN UPPER STD |
| 2. | NSS | [7] | NOT SOLD SEPARAT | CONBEARING,MAIN LOWER STD |
| 3. | VAME020328 | [3] | THRUST PLATE | KOBPLATE.THRUST STD Superseded by part number: VAME013564 |
| 3. | VAME020329 | [1] | THRUST PLATE O.S 0.1 PLATE.THRUST, OS 6.15 | THRUST PLATE O.S 0.1 PLATE.THRUST, OS 6.15 |
| 3. | VAME020330 | [1] | PLATE THRUST O.S. PLATE.THRUST ,OS 0.30 | PLATE THRUST O.S. PLATE.THRUST ,OS 0.30 |
| 3. | VAME020331 | [1] | METAL 045 PLATE.THRUST ,OS 0.45 | METAL 045 PLATE.THRUST ,OS 0.45 |
