神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-004 ) - FLYWHEEL HOUSING, ASSY Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
805 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1-4. | VAME088381 | [1] | FLYWHEEL HOUSING ASSY, FOR M6 ONLY | |
| 1-4. | VAME088383 | [1] | FLY SH FLYWHEEL HOUSING ASSY, M16, FOR M5 ONLY | FLY SH FLYWHEEL HOUSING ASSY, M16, FOR M5 ONLY |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONHOUSING,F/W |
| 3. | VAME031063 | [1] | CONTROL POINTER | CONTROL POINTER |
| 4. | VAMF200049 | [1] | SCREW | KOBSCREW,MACHINE 5X8 |
| 5. | VAME020359 | [2] | PLUG | KOBPLUG, DUST Superseded by part number: VAME609555 |
| 6. | VAMH000969 | [12] | BOLT,FLANGE (10X28) BOLT,FLAHGE 10X28 | BOLT,FLANGE (10X28) BOLT,FLAHGE 10X28 |
| 7. | VAMH000727 | [2] | BOLT | KOBBOLT,FLANGE 12X30 |
