卡特零件查询（725C） 396-1961: BATTERY GP
广数供应链运营团队, 14 02月, 2025，浏览：
257 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 396-9871 | [1] | PLATE AS | |
| | 8T-3490M | [8] | NUT-WELD(M10X1.5-THD) | |
| 2. | 460-0301 | [2] | STUD | |
| 3. | 433-6366 | [1] | PLATE AS | |
| | 178-7023M | [2] | BOSS(M10X1.5X30-MM) | |
| 4. | 153-5700 | [2] | BATTERY AS(12-VOLT, 1125-CCA) | |
| | | | (EACH INCLUDES) |
| | 123-1373 | [6] | CAP AS-FILLER(7/8-9-THD) | |
| 5. | 206-0154 | [1] | CABLE AS | |
| | 159-8049E | | CABLE(00-GA, RED)(43-CM) | |
| | 7N-5274 | [1] | COVER AS-TERMINAL(BLACK) | |
| | 8N-1725 | [1] | COVER AS-TERMINAL(RED) | |
| | | | (EACH COVER AS INCLUDES) |
| | 8L-8413 | [1] | STRAP-CABLE(WHITE) | |
| | 3S-6050 | [1] | TERMINAL AS-BATTERY(NEGATIVE) | |
| | 3S-6049 | [1] | TERMINAL AS-BATTERY(POSITIVE) | |
| | | | (EACH TERMINAL AS INCLUDES) |
| | 1M-6119 | [1] | BOLT(5/16-18X1.375-IN) | |
| | 1M-6120 | [1] | NUT(5/16-18-THD) | |
| 6. | 263-6342 | [3] | CLIP | |
| 7. | 2G-8767 | [2] | WASHER(10.5X60X3-MM THK) | |
| 8. | 384-3775 | [1] | CABLE AS-BATTERY | |
| | 159-8050E | | CABLE(00-GA, BLACK)(90-CM) | |
| | 3S-6050 | [1] | TERMINAL AS-BATTERY(NEGATIVE) | |
| | 1M-6119 | [1] | BOLT(5/16-18X1.375-IN) | |
| | 1M-6120 | [1] | NUT(5/16-18-THD) | |
| | 1S-7252 | [1] | TERMINAL-CABLE(00-GA, 3/8-IN SCREW) | |
| | 7N-5274 | [1] | COVER AS-TERMINAL(BLACK) | |
| | | [1] | STRAP |
| | 037-5197 | [1] | BOOT | |
| 9. | 384-3781 | [1] | CABLE AS-BATTERY | |
| | 159-8049E | | CABLE(00-GA, RED)(85-CM) | |
| | 8N-0869 | [1] | COVER-TERMINAL(RED) | |
| | 8N-1725 | [1] | COVER AS-TERMINAL(RED) | |
| | 8L-8413 | [1] | STRAP-CABLE(WHITE) | |
| | 3S-6049 | [1] | TERMINAL AS-BATTERY(POSITIVE) | |
| | 1M-6119 | [1] | BOLT(5/16-18X1.375-IN) | |
| | 1M-6120 | [1] | NUT(5/16-18-THD) | |
| | 235-2677 | [1] | TERMINAL-RING | |
| 10. | 385-5063 | [1] | PLATE | |
| 11. | 553-6904 | [1] | PLATE | |
| 12. | 6G-2256 | [2] | CLAMP | |
| 13. | 7X-7729 | [6] | WASHER(11X25X3-MM THK) | |
| 14. | 8T-0389M | [2] | LOCKNUT(M10X1.5-THD) | |
| 15. | 8T-4121 | [5] | WASHER-HARD(11X21X2.5-MM THK) | |
| 16. | 8T-4136M | [11] | BOLT(M10X1.5X25-MM) | |
| | E | | ORDER BY THE CENTIMETER |
| | M | | METRIC PART |
