| 1. |
84385997
|
[1] |
DIA KIT, HARVESTER
|
PLO
Hydraulic Rotor Reverser, Incl 2 - 39 plus Figures 88.100.35 01 and 88.100.35 03
|
| 2. |
84572204
|
[1] |
ARM
|
PLO
|
| 3. |
87394426
|
[1] |
ARM
|
NH
|
| 4. |
47400925
|
[1] |
DOG
|
PLO
|
| 5. |
84552023
|
[1] |
SUPPORT
|
PLO
|
| 6. |
86629541
|
[1] |
BOLT,Hex, M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 7. |
32306
|
[1] |
SPRING
|
NH
|
| 8. |
321018
|
[1] |
CLEVIS PIN,12mm OD x 44mm L
|
PA
|
| 9. |
165238
|
[1] |
WASHER,45.2mm ID x 63.5mm OD x 1.24mm Thk
|
PA
Superseded by part number: T42195
|
| 10. |
762217
|
[2] |
WASHER
|
BEL
|
| 11. |
47401439
|
[1] |
SHAFT,M12 x 1.75
|
PLO
|
| 12. |
86634543
|
[1] |
SPACER
|
NH
|
| 13. |
87023405
|
[1] |
SPACER,13.64mm ID x 19.18mm OD x 22.9mm L
|
NH
|
| 14. |
87652388
|
[2] |
WASHER,45.24mm ID x 56.36mm OD x 1.52mm Thk
|
NH
|
| 15. |
86592700
|
[1] |
WASHER,10.5mm ID x 28mm OD x 4mm Thk
|
ZED
|
| 16. |
280963
|
[1] |
NUT,Nut, 1/2-20 GR 5 ZND
|
NH
|
| 17. |
87362
|
[1] |
WASHER,5/16" SAE
|
NH
Superseded by part number: 83918746
|
| 18. |
213137
|
[1] |
WASHER,6.76mm ID x 25.4mm OD x 3.17mm Thk
|
NH
|
| 19. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 20. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 21. |
9804256
|
[1] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 22. |
43130
|
[1] |
BOLT,Hex, M8 x 1.25 x 50mm, Cl 8.8
|
NH
|
| 23. |
43139
|
[1] |
BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
Superseded by part number: 11106231
|
| 24. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 25. |
11487
|
[1] |
SNAP RING,#175, Ext
|
NH
|
| 26. |
87414
|
[2] |
LUBE NIPPLE,1/4" - 28
|
NH
|
| 27. |
86630617
|
[2] |
WASHER
|
PA
|
| 28. |
84347289
|
[2] |
HUB
|
PLO
|
| 29. |
86627455
|
[3] |
CLEVIS,1/2" - 20
|
GI
|
| 30. |
86705722
|
[1] |
THREADED ROD
|
PA
|
| 31. |
29790
|
[1] |
NUT,1/2" - 20
|
NH
|
| 32. |
87309
|
[5] |
JAM NUT,Jam, 1/2"-20, G2
|
NH
|
| 33. |
76877
|
[2] |
CLEVIS PIN,12.6mm OD x 34.52mm L
|
NH
|
| 34. |
80755
|
[3] |
COTTER PIN,1/8" OD x 1" L
|
NH
|
| 35. |
86705723
|
[1] |
THREADED ROD
|
PA
|
| 36. |
86000021
|
[2] |
BEARING LOCK NUT,M12, Cl 8
|
ZED
Superseded by part number: 9706685
|
| 37. |
84578315
|
[1] |
WASHER
|
PLO
|
| 38. |
65319
|
[1] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 39. |
86705574
|
[1] |
HUB
|
PA
|
| 40. |
86577603
|
[1] |
BUSHING,98.6mm ID x 103.18mm OD x 25.4mm L
|
PA
|
