凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (88.100.35[03]) - DIA KIT, REVERSER SHIELD Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
272 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84385997
|
[1] |
DIA KIT, HARVESTER
|
PLO
Hydraulic Rotor Reverser, Incl 2 - 39 plus Figures 88.100.35 01 and 88.100.35 02
|
| 2. |
86512919
|
[1] |
LATCH
|
PA
|
| 3. |
9804256
|
[2] |
BOLT,Hex, M6 x 1 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 4. |
52367
|
[1] |
HOLDER
|
NH
|
| 5. |
46520
|
[4] |
BOLT AND NUT,Hex, 1/4" - 20 x 1 1/2"
|
GI
Incl 6
|
| 6. |
20356
|
[4] |
NUT,1/4"-20, GB
|
PA
Superseded by part number: 280129
|
| 7. |
47438769
|
[1] |
SHIELD
|
PLO
1.8M
|
| 7. |
47441393
|
[1] |
SHIELD
|
PLO
2M
|
