神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (01-008 ) - PISTON Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
263 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME012858 | [6] | PISTON | KOBPISTON STD |
| 1. | VAME012859 | [1] | PISTON | KOBPISTON,OS 0.25 |
| 1. | VAME012860 | [1] | PISTON | KOBPISTON,OS 0.50 |
| 1. | VAME012861 | [1] | PISTON | KOBPISTON,OS 0.75 |
| 1. | VAME012862 | [1] | MANIFOLD PISTON,OS 1.00 | MANIFOLD PISTON,OS 1.00 |
| 2-4. | VAME999836 | [1] | PISTON RINGS KIT | KOBPISTON RING SET,ONE MODEL STD Superseded by part number: VAME997458 |
| 2-4. | VAME999837 | [1] | PISTON RING | KOBPISTON RING SET,OS 0.25 |
| 2-4. | VAME999838 | [1] | PISTON RING | KOBPISTON RING SET,OS 0.50 Superseded by part number: VAME997460 |
| 2-4. | VAME999839 | [1] | PISTON RING SET,OS 0.75 | |
| 2-4. | VAME999840 | [1] | RING SET,PISTON PISTON RING SET,OS 1.00 | RING SET,PISTON PISTON RING SET,OS 1.00 |
| 2. | NSS | [6] | NOT SOLD SEPARAT | CONRING,COMPRESSION NO.1 STD |
| 3. | NSS | [6] | NOT SOLD SEPARAT | CONRING,COMPRESSION NO.2 STD |
| 4. | NSS | [6] | NOT SOLD SEPARAT | CONRING,OIL STD |
| 5. | VAME012009 | [6] | PISTON PIN | KOBPIN,PISTON |
| 6. | VAME012061 | [12] | SNAP RING | KOBRING,SNAP Superseded by part number: VAME015917 |
