凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (88.100.37[01]) - DIA KIT, LOCKING HITCH PIN AND PTO SUPPORT, YFN188618 AND PRIOR Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
433 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47531822
|
[1] |
DIA KIT, HARVESTER
|
NH
Locking Hitch Pin and PTO Support, Incl 2 - 7
|
| 2. |
84555189
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
86625254
|
[1] |
WASHER,13.5mm ID x 28mm OD x 2.5mm Thk
|
FAR
|
| 4. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 5. |
47523471
|
[1] |
PIN
|
NH
|
| 6. |
129365
|
[1] |
COTTER PIN
|
NH
|
| 7. |
47523478
|
[1] |
BRACKET
|
NH
|
| 8. |
309308
|
[1] |
BOLT,Hex, M12 x 1.75 x 120mm, Cl 8.8
|
NH
|
