凯斯零件查询(RB465) - CASE IH ROUND BALER - NORTH AMERICA (5/14-12/15) (88.100.37[02]) - DIA KIT, LOCKING HITCH PIN AND PTO SUPPORT Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
429 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47773743
|
[1] |
DIA KIT, HARVESTER
|
NH
Locking Hitch Pin and PTO Support, Incl 2 - 8
|
| 2. |
84555189
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
86625254
|
[1] |
WASHER,13.5mm ID x 28mm OD x 2.5mm Thk
|
FAR
|
| 4. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 5. |
47523471
|
[1] |
PIN
|
NH
|
| 6. |
129365
|
[1] |
COTTER PIN
|
NH
|
| 7. |
47523478
|
[1] |
BRACKET
|
NH
|
| 8. |
300308
|
[1] |
SOLENOID
|
CUR
Superseded by part number: BN300308
|
| 9. |
87666884
|
[1] |
PIN
|
NH
|
