神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (02-002 ) - WATER PIPE & THERMOSTAT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
726 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME085512 | [1] | RIGID TUBE | KOBPIPE,WATER |
| 2. | VAME080071 | [1] | PIPE | KOBPIPE,BY-PASS |
| 2A. | VAM0001300 | [1] | PLUG | KOBPLUG |
| . . | VAMF660066 | [1] | GASKET | KOBGASKET 16 Superseded by part number: VAF420216000 |
| 3. | VAMF520016 | [4] | O-RING | KOBO-RING 22.1 |
| 5. | VAME080107 | [1] | CASE | KOBCASE THERMOSTAT |
| 5. | VAME080296 | [1] | CASE | KOBCASE THERMOSTAT |
| 7. | VAME015420 | [1] | GASKET | KOBGASKET,THERMOSTAT Superseded by part number: VAME014498 |
| 8. | VAMH000714 | [2] | BOLT | KOBBOLT,FLANGE 10X25 |
| 8. | VAMH000712 | [2] | SCREW | KOBBOLT,FLANGE 10X65 |
| 9-10. | VAME999516 | [1] | SENSOR | KOBTHERMOSTAT KIT 76.5°C Superseded by part number: VAME995106 |
| 9. | VAME015380 | [1] | SENSOR | KOBTHERMOSTAT 76.5°C Superseded by part number: VAME995106 |
| 10. | VAME015421 | [1] | GASKET | KOBGASKET Superseded by part number: VAME014499 |
| 11. | VAME015429 | [1] | COVER | KOBCOVER,THERMOSTAT |
| 12. | VAMF140229 | [3] | BOLT | KOBBOLT,FLANGE 8X30 |
| 13A. | VAM0001300 | [1] | PLUG | KOBPLUG |
| 15. | VAMS666224 | [1] | PLUG | KOBPLUG,TAPER PT3/4 |
