神钢零件查询(6D31-T) - MITSUBISHI DIESEL ENGINE (1/06-12/06) (02-004 ) - FAN & PULLEY Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
1018 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAME018185 | [1] | FAN | KOBFAN,SUCTION TYPE PPG 600 |
| 2. | VAME088133 | [1] | SPACER | KOBSPACER 1=85 |
| 3. | VAME088288 | [1] | DRIVEN SPROCKET | KOBPUILEY.WATER PUMP D168 AX2 |
| 4. | VA3004891500 | [1] | SPACER | KOBPLATE |
| 6. | VAMF300845 | [4] | BOLT | KOBBOLT,W / WSRr 10X30 |
| 7. | VAMH000724 | [4] | SCREW | KOBBOLT,FLANGE 10X85 Superseded by part number: 132669A1 |
| 10. | VAME902206 | [1] | BELT, TRANSMISSION | KOBV-BELT, 2BELTS SET A 1=1190 Superseded by part number: VAMH014090 |
